  4.InstallationSpecications
4-6
TI 32P01J10-01EN
 Maximum Current Consumption of N-IO
Mode Name Max current consumption 24 V DC (A)
S2BN1D Base Plate (Field Power Supply) 11 A
S2BN4D Base Plate for Barrier (Barrier Power Supply) 1.6 A
S2BN5D Base Plate for Barrier (Barrier Power Supply) 1.8 A
 Fuse (Breaker) Specications
Fuse (breaker) ratings are listed below.
Table Fuse (Breaker) Ratings
Equipment
Built-in fuse
rating (A/V)
External breaker
rating (A/V) (*1)
SNT10D Unit for Optical Bus Repeater Module (for 100 V or 220 V AC power supply) 6.3/250 15/250
SNT10D Unit for Optical Bus Repeater Module (for 24 V DC power supply) 10/250 20/250
SSC60S/SSC60D Safety Control Unit (for 100 V AC power supply) 6.3/250 15/250
SSC60S/SSC60D Safety Control Unit (for 220 V AC power supply) 6.3/250 15/250
SSC60S/SSC60D Safety Control Unit (for 24 V DC power supply) 10/250 20/250
SSC50S/SSC50D Safety Control Unit (for 100 V AC power supply) 6.3/250 15/250
SSC50S/SSC50D Safety Control Unit (for 220 V AC power supply) 6.3/250 15/250
SSC50S/SSC50D Safety Control Unit (for 24 V DC power supply) 10/250 20/250
SSC57S/SSC57D Safety Control Unit (for 100 V AC power supply) 6.3/250 15/250
SSC57S/SSC57D Safety Control Unit (for 220 V AC power supply) 6.3/250 15/250
SSC57S/SSC57D Safety Control Unit (for 24 V DC power supply) 10/250 20/250
S2SC70S/S2SC70D Safety Control Unit (for 100 V AC power supply) 6.3/250 15/250
S2SC70S/S2SC70D Safety Control Unit (for 220 V AC power supply) 6.3/250 15/250
S2SC70S/S2SC70D Safety Control Unit (for 24 V DC power supply) 10/250 20/250
SNB10D Safety Node Unit (for 100 V or 220 V AC power supply) 6.3/250 15/250
SNB10D Safety Node Unit (for 24 V DC power supply) 10/250 20/250
AVR10D Duplexed V net router (for 100 V or 220 V AC power supply) 3.15/250 10/250
AVR10D Duplexed V net router (for 24 V DC power supply) 6.3/250 15/250
S2NN30D Node Interface Unit (100-240 V AC system) 5/250 (fuse) 15/250
S2NN30D Node interface Unit (24 V DC) 12/250 (fuse) 30/24
S2BN1D Base Plate with disconnecting terminal — —
S2BN4D Base Plate for Barrier (MTL): Barrier Power Input (24 V DC) 2.5/250 (fuse) —
S2BN5D Base Plate for Barrier (P+F): Barrier Power Input (24 V DC) 3.15/250 (fuse) —
*1: Recommended.
