YOKOGAWA ProSafe-RS User Manual

  4.InstallationSpecications
4-5
TI 32P01J10-01EN
 Maximum Current Consumption of FIO Modules
Table Maximum Current Consumption of I/O Modules
Model Name
Maximum current
consumption (mA)
5 V DC
Maximum current
consumption (mA)
24 V DC
Analog Input/Output Module
SAI143-S
Analog input module
(4 to 20 mA, 16 channels, Module isolation)
320 550
SAI143-H
Analog input module (4 to 20 mA, 16 channels,
Module isolation, HART communication)
320 550
SAV144
Analog input module
(1 to 5 V/1 to 10 V, 16 channels, Module isolation)
300 140
SAI533
Analog output module (4 to 20 mA, 8 channels,
Module isolation, HART communication)
320 300
SAT145 TC/mV input module (16 channels, Isolated Channels) 400 200
SAR145 RTD input module (16 channels, Isolated Channels) 500 200
Digital Input/Output Module
SDV144
Digital input module
(non-voltage contact, 16 channels, Module isolation)
290 140
SDV521
Digital output module
(24 V DC/2 A, 4 channels, Module isolation)
280 140
SDV526
Digital output module
(100-120 V AC, 4 channels, Module isolation)
500 50
SDV531
Digital output module
(24 V DC, 8 channels, Module isolation)
280 140
SDV53A
Digital output module
(48 V DC, 8 channels, Module isolation)
290 150
SDV541
Digital output module
(24 V DC, 16 channels, Module isolation)
300 150
ESB Bus Interface Module
SNT401 Optical ESB Bus Repeater Master Module 500 0
SNT501 Optical ESB Bus Repeater Slave Module 500 0
SNT411
Optical ESB Bus Repeater Master Module 5 km - 50 km 500 -
SNT511
Optical ESB Bus Repeater Slave Module 5 km - 50 km 500 -
Communication Module
ALR111 Serial communication module (RS-232C, 2-port) 500 -
ALR121
Serial communication module
(RS-422/RS-485, 2-port)
500 -
ALE111 Ethernet communication module (1-port) (*1) 500 -
S2LP131 Fire and gas communication module (1-port) (*2) 800 -
Bus Interface Module
SEC402 ESB Bus Coupler Module
( 2-Port ) 500 -
SEC401 ESB Bus Coupler Module 500 -
S2EN402 N-ESB Bus Coupler Module
( 2-Port ) 500 -
S2EN404 N-ESB Bus Coupler Module
(4 -Port ) 500 -
*1: ALE111 is available from ProSafe-RS R3.02.00 or later with S2SC70, SSC60, SSC50 or SSC57.
*2: S2LP131 is available from ProSafe-RS R4.03.10 or later with S2SC70.
