1. System Installation Requirements
1-32
TI 32P01J10-01EN
Product Model Module Type Description
Input/Output Module
SDV144
Digital input module (16 channels,
contact input and module isolation)
(*2)
SDV144-SC does not comply.
SDV521
Digital output module (4 channels,
24 V DC/2A, and module isolation)
SDV521-S3C does not comply.
SDV531
Digital output module (8 channels,
24 V DC, and module isolation)
(*2)
SDV531-L complies with Marine
Standards from style code S3.
SDV531-LC does not comply.
SDV53A
Digital output module (8 channels,
48 V DC, and module isolation)
SDV541
Digital output module (16 channels,
24 V DC, and module isolation)
(*2)
SDV541-SC does not comply.
SDCV01 Dummy cover (for I/O modules)
Wiring Check Adapter
SCB100
Wiring check adapter for digital
input
SCB110
Unit for Optical Bus
Repeater Module
SNT10D
Unit for optical bus repeater
module
Including SPW481, SPW482 and
SPW484.
Optical ESB bus
repeater module
SNT401
Optical ESB bus repeater master
module
SNT411
Optical ESB bus repeater master
module 5 km to 50 km
SNT501
Optical ESB bus repeater slave
module
SNT511
Optical ESB bus repeater slave
module 5 km to 50 km
ESB Bus Interface
Module
SEC402
ESB bus coupler module
SEC401
N-ESB Bus Coupler
Module
S2EN402
N-ESB Bus coupler Module
(for 2-port)
S2EN404
N-ESB Bus coupler Module
(for 4-port)
Cover S2DCV02
Dummy cover
(for N-IO I/O module)
Communication Module
ALR111
Serial communications module
(RS-232C, 2-port)
ALR121
Serial communications module
(RS-422/RS-485, 2-port)
ALE111 Ethernet communication module
S2LP131
Fire and Gas Communication
Module
Terminal Board
SEA4D
Analog terminal board (single and
dual-redundant, 16 channels x 2)
SED2D
Digital terminal board (single and
dual-redundant, 4 channels x 4)
SED3D
Digital terminal board (single and
dual-redundant, 8 channels x 4)
SED4D
Digital terminal board (single and
dual-redundant, 16 channels x 2)
SBT4D
Terminal board for TC/mV: DIN
rail mount type (Single and Dual-
redundant, 16 channels x 1)
SBR4D
Terminal board for RTD input: DIN
rail mount type (Single and Dual-
redundant, 16 channels x 1)
SBA4D
Terminal board for Analog: DIN
rail mount type (Single and Dual-
redundant, 16 channels x 1)
Mar. 15, 2018-00
*2: Including SCCC01,SCCC02, STB4D, STB4S and STD4A.
Table Marine Standard-compliant ProSafe-RS Components (2/3)
