YOKOGAWA ProSafe-RS

1. System Installation Requirements
1-33
TI 32P01J10-01EN
Product Model Module Type Description
Terminal Board
SBD2D
Terminal board for Digital output:
DIN rail mount type (Single and
Dual-redundant, 4 channels x 1, for
SDV521)
SBD3D
Terminal board for Digital output:
DIN rail mount type (Single and
Dual-redundant, 8 channels x 1, for
SDV53)
SBD4D
Terminal board for Digital: DIN rail
mount type (Single and Dual-
redundant, 16 channels x 1, for
SDV144/SDV541)
S1BB4D
Terminal Board for Analog Input,
3-wire: DIN rail mount type
Relay Board
SRM53D
Relay Board
(8 × 2 dry contact output)
SRM54D
Relay Board
(16 × 1 dry contact output)
SBM54D
Relay board for Digital output: DIN
rail mount type (Single and Dual-
redundant, 16 channels x 1, for
SDV541)
Control Bus Interface VI702 Control bus interface card (*3)
V net Router
AVR10D
-1
Duplexed V net router
AVR10D-0 does not comply.
Cable, etc.
YCB301 ESB bus cable
AKB651
Signal cable (50 - 50 pins)
(for connections between SDV521
and Terminal Board)
When AKB651 is connected to
SDV531-L, SDV53A or SDV541,
it does not comply.
AKB331 Signal cable (50 - 50 pins)
AKB136
RS-232C null modem cable
(9 - 25 pins)
AKB161 RS-422/RS-485 cable
AKB611
Signal cable (for connections
between SAR145 and Terminal
Board)
KS1 Signal cable (40 - 40 pins)
YCB146 T-shaped control bus connector
YCB128 Terminator for IRIG (GPS)
S2KLF10 F-SB bus cable
S2KPB10 Power supply cable for Base plate
*3: Noisecut transformer shall be attached in the power-line cable of SENG.
 Precaution on Selecting System Components
When building a system, use components which have already obtained type approval for marine
standards. For the SENG and HISs too, use generic computers (including monitors, keyboards,
mice, and other peripheral devices) which are accredited by the required marine standards.
Nov. 14, 2017-00
Table Marine Standard-compliant ProSafe-RS Components (3/3)
