YOKOGAWA ProSafe-RS

1. System Installation Requirements
1-37
TI 32P01J10-01EN
Component Description
Ferrite Core
Model (*1)
Quantity
Location
(See the
Figures)
External power
supply (output
side)
Power Supply
(SDV531, SDV541)
DC power cable
(Output side)
ZCAT3035-1330 3 (7)
ZCAT2032-0930 1
Power Supply
(SDV521, SDV53A)
DC power cable
(Output side)
ZCAT3035-1330 1
Noise lter
(Input side)
AC power-line lter AC power cable ZCAT3035-1330 1 (8)
ZCAT2032-0930 3
ZCAT3035-1330 1 (9)
ESB bus coupler
module
SEC402 ESB bus cable ZCAT3035-1330 5 (10)
SEC401 ESB bus cable ZCAT3035-1330 5 (10)
ZCAT3035-1330 1 (11)
ESB bus interface
module
SSB401 ESB bus cable ZCAT3035-1330 4 (12)
ZCAT3035-1330 1 (13)
Optical ESB bus
repeater module
SNT401 ESB bus cable ZCAT3035-1330 1 (14)
SNT501 ESB bus cable ZCAT3035-1330 1 (15)
CPU SCP461 Vnet/IP cable ZCAT3035-1330 1 (16)
SCP451 Vnet/IP cable ZCAT3035-1330 3 —
Fan unit
SSC60
-F Fan unit
Flat cable ZCAT3035-1330 1 — (*3)
SSC50
-F Fan unit
Flat cable ZCAT3035-1330 1 — (*3)
SSC57
-F Fan unit
Flat cable ZCAT3035-1330 1 — (*3)
Analog module SAI143 KS1 cable ZCAT3035-1330 4 (17)
SAV144
SAI533
Digital module SDV144 AKB331 cable ZCAT3035-1330 3 (18)
SDV521 AKB651 cable ZCAT3035-1330 4
SDV531 AKB331 cable ZCAT3035-1330 3
SDV53A AKB331 cable ZCAT3035-1330 3
SDV541 AKB331 cable ZCAT3035-1330 3
Terminal board SEA4D KS1 cable ZCAT3035-1330 1 (19)
SED4D AKB331 cable ZCAT3035-1330 1 (20)
Relay board SRM53D AKB331 cable ZCAT3035-1330 3 —
SRM54D
Bus converter VC401 V net cable ZCAT3035-1330 4 (21)
VI451 Vnet/IP cable ZCAT3035-1330 4 (22)
N-ESB bus
coupler modules
S2EN402 N-ESB Bus cable — — —
S2EN404 N-ESB Bus cable — — —
Oct. 25, 2016-00
Table Cables that Need Ferrite Cores to be Attached to, and Ferrite Core Models and Quantities for
Vnet/IP (2/3)
*1: Quantity “—“, Ferrite core is not necessary.
*2: The part number of ZCAT3035-1330 is A1179MN, and ZCAT2032-0930 is A1193MN.
Models ZCAT3035-1330 and ZCAT2032-0930 are from TDK Corporation.
*3: The component is mounted on the standard model.
