YOKOGAWA ProSafe-RS User Manual

1. System Installation Requirements
1-42
TI 32P01J10-01EN
Cabinet
PDU VI451 VI451 VC401 VC401
PW44 PW44
AVR10D
for HUB
Noise
Filter
for AIP451
Note: Figures in ( ) show the locations listed in "Table Cables that Need Ferrite Cores to be
Attached to, and Ferrite Core Models and Quantities". It is NOT a number of ferrite core.
F010805.ai
(8)
(4) (21) (21)
(22) (22)
(4)
Figure Locations of Ferrite Core Installation for AVR10D
Oct. 25, 2016-00
