YOKOGAWA UP55A - Introduction to Functions; UP55 A Operating Procedures; Part Names; Basic Operation

IM 05P02C41-15EN page 14/14
n
DeviceNet Communication Setting Parameter (E3-terminal Area)
Menusymbol: (DNET)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(BR)
Baud rate
125K:125kbps
250K:250kbps
500K:500kbps
125K
EASY
(ADR)
Address 0to
63 63
(BPS)
Baud rate
9600:9600bps
19200:19.2kbps
38400:38.4kbps
38400
(FILE)
Prolenumber 0,11to15 0
n
CC-Link Communication Setting Parameter (E3-terminal Area)
Menusymbol: (CC-L)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(BR)
Baud rate
156K:156kbps
625K:625kbps
2.5K:2.5kbps
5M:5Mbps
10M:10Mbps
10M
EASY
(ADR)
Address 1 to
64 1
(BPS)
Baud rate
9600:9600bps
19200:19.2kbps
38400:38.4kbps
38400
(FILE)
Prolenumber
0,11to15
(0,11:Ver.1.10)(12to15:Ver.2.00)
0
■DisplayFunctionSettingParameter
Menusymbol: (DISP)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(PCMD)
ActivecolorPVdisplay
switch
0:Fixed
inwhite
1:Fixedinred
2:Linktoalarm1(AlarmOFF:white,
AlarmON:red)
3:Linktoalarm1(AlarmOFF:red,
AlarmON:white)
4:Linktoalarm1or2(AlarmOFF:
white,AlarmON:red)
5:Linktoalarm1or2(AlarmOFF:
red,AlarmON:white)
6:PVlimit(Withinrange:white,Out
ofrange:red)
7:PVlimit(Withinrange:red,Outof
range:white)
8:SPdeviation(Withindeviation:
white,Outofdeviation:red)
9:SPdeviation(Withindeviation:red,
Outofdeviation:white)
10:LinktoDI(ON:red,OFF:white)
0
EASY
(PCH)
PVcolorchangehigh
limit
Seta
displayvaluewheninPVlimit
orSPdeviation.
-19999to30000(Setavaluewithin
theinputrange.)
Decimalpointpositiondependson
the input type.
0
(PCL)
PVcolorchangelowlimit 0
(PTSL)
Programdisplaypattern
selection
PTN:Pattern
display
SK.RP:Rampandsoakdisplay
PTN
STD
(BAR1)
Upperbar-graphdisplay
registration
0:Disable
1:
OUT,Heating-sideOUT,Internalvalue
in Position proportional control
2:Cooling-sideOUT
3:PV
4: SP
5:Deviation
6:
Loop-2OUT,Loop-2heating-sideOUT
7:Loop-2cooling-sideOUT
8:Loop-2PV
9:Loop-2SP
10:Loop-2deviation
11to16:Disable
17:Feedbackinput(valveopening)
18:PVterminalsanaloginput
19:RSPterminalsanaloginput
20:AIN2terminalsanaloginput
21:AIN4terminalsanaloginput
22:Segmentprogress
23:Timeeventandalarmstatus
23
(BAR2)
Lowerbar-graphdisplay
registration
0
(BDV)
Bar-graphdeviation
displayband
0.0to100.0%ofPVinputrangespan
(EUS)
10.0%

ofPV
input
range
span
STD
(GUID)
GuidedisplayON/OFF OFF:Nondisplay,ON:Display ON
(ECO)
Economymode
OFF:Disable
1:EconomymodeON(Allindications
exceptPVdisplayOFF)
2:EconomymodeON(Allindications
OFF)
3:Brightness
10%(wholeindication)
OFF
(BRI)
Brightness (Dark)1
to5(Bright) 3 EASY
(MLSD)
Leastsignicantdigital
maskofPVdisplay
OFF:Withleastsignicantdigit
ON:Withoutleastsignicantdigit
OFF STD
■SELECTDisplaySettingParameter
Menusymbol: (CSEL)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
to
(CS1toCS5)
SELECTDisplay-1to-5
registration
Registerthe
operationparameter
(excepttheOperationMode)thatis
frequentlymodiedtodisplayitinthe
OperationDisplay.
OFF,2201to5000
Forthesettingrange,seeUser's
Manual.
OFF STD
Use
the
followingtabletorecordSELECTDisplaysettingvalue.
Parameter n=1 n=2 n=3 n=4 n=5
CSn
■KeyLockSettingParameter
Menusymbol: (KLOC)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(COM.W)
Communicationwrite
enable/disable
OFF:Enable,
ON:Disable OFF
STD
(DATA)
Front panel parameter
data(▼,▲)keylock
OFF:Unlock,ON:Lock
OFF
(RUN)
FrontpanelRUNkey
lock
OFF
(RST)
FrontpanelRSTkeylock OFF
(PTN)
FrontpanelPTNkeylock OFF
(MODE)
FrontpanelMODEkey
lock
OFF
■DIFunctionRegistrationParameter
Menusymbol: (DI.SL)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(PRG)
SwitchtoPROG(Start
ofprogramoperation)
SetanIrelaynumberofcontact
input.
Set“OFF”
todisablethefunction.
Standard terminals
DI1:5025,DI2:5026,DI3:5027
E1-terminalarea
DI11:
5041,DI12:5042,DI13:5043,
DI14:5044,DI15:5045,DI16:5046
E2-terminalarea
DI21:5057,
DI22:5058,DI23:5059,
DI24:5060,DI25:5061,DI26:5062
E3-terminalarea
DI31:5073,
DI32:5074,DI33:5075,
DI34:5076,DI35:5077
E4-terminalarea
DI41:5089,
DI42:5090,DI43:5091,
DI44:5092,DI45:5093,DI46:5094
5025
STD
(RST)
SwitchtoRESET(Stop
ofprogramoperation)
5026
(LOC)
SwitchtoLOCAL(LSP)
(Startoflocal-mode
operation)
5027
(REM)
SwitchtoREMOTE 5046
(P/R)
PROG/RESETSwitch OFF
(P/H)
PROG/HOLDSwitch OFF
(P/L)
PROG/LOCAL(LSP)
Switch
OFF
(HOLD)
SwitchtoHOLD(Start
ofhold-modeoperation)
OFF
(ADV)
Advanceofsegment OFF
(WAIT)
WaitON/OFFswitch OFF
(A/M)
AUTO/MANswitch OFF
(AT)
Auto-tuningSTART/STOP
switch
OFF
(LAT)
Latchrelease OFF
(LCD)
LCDbacklightON/OFF
switch
OFF
(PVRW)
PVred/whiteswitch OFF
■DIFunctionNumberingParameter
Menusymbol: (DI.NU)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(PT.B0)
Bit-0ofprogrampattern
number
Seenext
table.
5089
EASY
(PT.B1)
Bit-1ofprogrampattern
number
5090
(PT.B2)
Bit-2ofprogrampattern
number
5091
(PT.B3)
Bit-3ofprogrampattern
number
5092
(PT.B4)
Bit-4ofprogrampattern
number
5093
(PT.B5)
Bit-5ofprogrampattern
number
Seta
nIrelaynumberofcontactinput.
Set“OFF”todisablethefunction.
Standard terminals
DI1:5025,
DI2:5026,DI3:5027
E1-terminalarea
DI11:
5041,DI12:5042,DI13:5043,
DI14:5044,DI15:5045,DI16:5046
E2-terminalarea
DI21:5057,DI22:5058,DI23:5059,
DI24:5060,DI25:5061,DI26:5062
E3-terminalarea
DI31:5073,
DI32:5074,DI33:5075,
DI34:5076,DI35:5077
E4-terminalarea
DI41:5089,
DI42:5090,DI43:5091,
DI44:5092,DI45:5093,DI46:5094
OFF
STD
(PN.B0)
Bit-0ofPIDnumber OFF
(PN.B1)
Bit-1ofPIDnumber OFF
(PN.B2)
Bit-2ofPIDnumber OFF
(PN.B3)
Bit-3ofPIDnumber OFF
(MP.B0)
Bit-0ofmanualpreset
outputnumber
OFF
(MP.B1)
Bit-1ofmanualpreset
outputnumber
OFF
(MP.B2)
Bit-2ofmanualpreset
outputnumber
OFF
■AL1-AL3FunctionRegistrationParameter
Menusymbol: (ALM)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(AL1.S)
AL1functionselection
SetanIrelaynumber.Fortheitems
otherthanbelow,seeUser'sManual.
Ex.)Setthenumber4353forAL1.S
to use the alarm 1.
Set“OFF”todisablethefunction.
Settingrange:4001to6304
Nofunction:OFF,
PVevent
1:4801,PVevent2:4802,
PVevent
3:4803,PVevent4:4805,
PVevent
5:4806,PVevent6:4807,
PVevent
7:4809,PVevent8:4810,
Timeevent1:4817,Timeevent2:4818,
Timeevent3:4819,Timeevent4:4821,
Time
event5:4822,Timeevent6:4823,
Time
event7:4825,Timeevent8:4826,
Time
event9:4833,Timeevent10:4834,
Timeevent11:4835,Timeevent12:4837,
Timeevent13:4838,Timeevent14:4839,
Tim
eevent15:4841,Timeevent16:4842,
Alarm1:4353,Alarm2:4354,
Alarm3:
4355,Alarm4:4357
Alarm5:
4358,Alarm6:4359,
Alarm7:
4361,Alarm8:4362
AUTO(ON)/MAN(OFF)status:4177
ProgramRESETstatus:4181
ProgramRUNstatus:4182
Localoperationstatus:4183
Remoteoperationstatus:4185
HOLDmodestatus:4189
Programadvancestatus:4187
Patternendsignal(1second):4265
Patternendsignal(3seconds):4266
Patternendsignal(5seconds):4267
Waitendsignal(1second):4257
Waitendsignal(3seconds):4258
Waitendsignal(5seconds):4259
Outputtracking(ON)switchingsignal:4186
FAIL(NormallyON)output:4256
4801
STD
(AL2.S)
AL2functionselection 4802
(AL3.S)
AL3functionselection 4803
(OR.S)
OUTrelayfunction
selection
OFF
(OR2.S)
OUT2relayfunction
selection
OFF
■DOSettingParameter(E1/E2/E3/E4-terminalArea)
Menusymbol: (DO)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(DO1.S)
DO11/DO21/DO31/DO41
function selection
SameasAL1.S
Set“OFF”todisablethefunction.
Initialvalue:
DO11=4805,DO12=4806
DO13=4807,DO14=4809,
DO15=4810,DO21=4817,
DO22=4818,DO23=4819
DO24=4821,DO25=4822,
DO31=4823,DO32=4825,
DO33=4826,DO34=4833,
DO35=4834,
DO41to
DO45=OFF
See left
Table
below
STD
(DO2.S)
DO12/DO22/DO32/DO42
function selection
See left
(DO3.S)
DO13/DO23/DO33/DO43
function selection
See left
(DO4.S)
DO14/DO24/DO34/DO44
function selection
See left
(DO5.S)
DO15/DO25/DO35/DO45
function selection
See left
UsethefollowingtabletorecordDOsettingvalue.
Parameter E1-terminalArea E2-terminalArea E3-terminalArea E4-terminalArea
DO1.S
DO2.S
DO3.S
DO4.S
DO5.S
■SystemSettingParameter
Menusymbol: (SYS)
Parameter
symbol
Name of Parameter Setting Range Initial value
User
setting
Display
level
(R.MD)
Restartmode
Sethowthecontrollershouldrecoverfrom
a power failure of 5 seconds or more.
CONT:Continueactionsetbefore
power failure.
MAN:StartfromMAN.
RESET:StartfromAUTOandRESET.
Outputsthepresetoutputvalue.
CONT
STD
(R.TM)
Restarttimer
Settimebetweenpoweronandthe
instant where controller starts compu-
tation.0
to10s
0
(EPO)
Input error preset
output
Setpresetoutputvaluewhentheinputburnout
orADCerroroccurs.Manualoutputispriori-
tizedwhen
theinputburnoutoccursinMAN.
0:Presetoutput
1:0%output
2:100%output
0 STD
(FREQ)
Powerfrequency AUTO,60:60Hz,50:50Hz AUTO
EASY
(QSM)
Quicksettingmode
OFF:Disable
ON:Enable
ON
(LANG)
Guidedisplay
language
ENG:English
FRA:
French
GER:German
SPA:Spanish
Dependson
the model
andsufx
codes
(PASS)
Passwordsetting 0(Nopassword)to65535 0
■ ErrorandVersionConrmationParameter(fordisplayonly)
Menusymbol: (VER)
Parameter
symbol
Name of Parameter Status record
Display
level
(PA.ER)
Parameter error status
EASY
(OP.ER)
Optionerrorstatus
(AD1.E)
A/Dconvertererrorstatus1
(AD2.E)
A/Dconvertererrorstatus2
(PV1.E)
Loop-1PVinputerrorstatus
(PV2.E)
Loop-2PVinputerrorstatus
(LA.ER)
Laddererrorstatus
(MCU)
MCUversion
(DCU)
DCUversion
(ECU1)
ECU-1version(E1-terminalarea)
(ECU2)
ECU-2version(E2-terminalarea)
(ECU3)
ECU-3version(E3-terminalarea)
(ECU4)
ECU-4version(E4-terminalarea)
(PARA)
Parameterversion
(H.VER)
Productversion
(SER1)
Serialnumber1
(SER2)
Serialnumber2
(MAC1)
MACaddress1(E3-terminalarea)
(MAC2)
MACaddress2(E3-terminalarea)
(MAC3)
MACaddress3(E3-terminalarea)
*TheparametersforLoop-2areunavailableinSingle-loopcontrol.
■ParameterDisplayLevelParameter
Menusymbol: (LVL)
Parameter
symbol
Name of Parameter Setting Range
Initial
value
User
setting
Display
level
(LEVL)
Parameterdisplaylevel
EASY:Easysettingmode
STD:Standardsettingmode
PRO:Professionalsettingmode
STD EASY
*For
Professionalsettingmode,seeUser’sManual.
Trademarks
● Our product names or brand names mentioned in this manual are
the trademarks or registered trademarks of Yokogawa Electric Corporation.
● Adobe, Acrobat, and Postscript are either registered trademarks or trademarks
of Adobe Systems Incorporated.
● Ethernet is a registered trademark of XEROX Corporation in the United States.
● Modbus is a registered trademark of Schneider Electric.
● PROFIBUS-DP is a registered trademark of PROFIBUS User Organization.
● DeviceNet is a registered trademark of Open DeviceNet Vendor Association.
● CC-Link is a registered trademark of CC-Link Partner Association.
● We do not use the TM or ® mark to indicate these trademarks or
registered trademarks in this manual.
● All other product names mentioned in this manual are trademarks
or registered trademarks of their respective companies.
