Yongnuo YN-622C User Manual

1. Installing the Batteries
2.Installing the Transceiver on the Camera (As
Transmitter)
※ Remove the batteries when the product
is not used for long time.
※ Please replace the both two batteries at
the same time.
Open the cover and install two AA
batteries (excluded)according to
the + and - marks , rechargeable
batteries of 1.2V can be used.
Replace the batteries when the
product does not work stably.
1). Unscrew the locking ring of the transceiver.
2). Slip the mounting foot into the hot shoe of the camera.
3). Turn the locking ring according to the direction
of arrow, the locking pin will protrude from the
mounting foot.
※ It is supported that install a flash on the hot shoe of
the transmitter(on-top flash).(p.17)
Preparation Before Use
6

Yongnuo YN-622C Specifications

Power

battery type	2x AA batteries (1.5v Alkaline or 1.2v NiMH)
standby time	60 hours
max safe trigger voltage on hot-shoe centre pin	6 volts

Connectors

canon hot foot	with locking ring and pin
canon hot shoe	for mounting hot-shoe flash
pc-sync screwlock socket	sync out only

Weight and Dimensions

dimensions	90 x 53 x 25mm (39mm incl. hot-foot)
weight	79gm without batteries
