Yongnuo YN560 User Manual

I
V
. Installation Instruction
1. Install Batteries
Slide the battery bay cover in the direction of the arrows to open.
Insert the batteries, with polarity according to the label inside battery
bay. Make sure the battery polarity is correct.
Close the battery bay cover in the direction of the arrows.
2. Mount the flash light on your camera
Loosen the locking ring by turning it in the direction
of the arrow. Slip the flash light hot shoe stand into
the camera hot shoe stand until it stops. Turn the
locking ring in the direction of the arrow tighten. To
detach the flash light, loosen the locking ring by
turning it in the opposite direction.

Yongnuo YN560 Specifications

General

Zoom Range	24-105mm
Recycle Time	Approx. 3 seconds
Power Source	4 x AA batteries (alkaline or Ni-MH)
Color Temperature	5600K
Flash Modes	Multi
Swivel Angle	270 degrees
Tilt Angle	0-90 degrees
Wireless Triggering	Yes
Manual Power Levels	1/1 to 1/128
