York ARC 045 - Limits of Use; Power and Application Data for Gas ARG; ARD

ARC Model
Electric power sup‐
ply V/Ph/Hz
Electric resistor
Maximum total current
of the unit (A)
Maximum circuit
breaker (K Curve) (1)
Minimum cable cross-
section (mm
2
) (2)
Power
(kW)
Stages (No.) Current (A)
25 2 36 106 125 50
37 2 54 124 160 70
50 2 72 142 160 70
(1) K Curve (DIN, VDE 0660-104).
(2) Based on copper conductors 105 °C.
1.7 Limits of use
Model 045 060 075 090
Voltage limits Min./Max V 342/457
ARC/ARG
Temperature of air input in indoor coil
TH °C Min./Max. 15/23 15/23 15/23 15/23
DB °C Min./Max. 20/32 20/32 20/32 20/32
Outdoor temperature (without condensa‐
tion control)
TS °C Min. 7 7 7 7
Maximum outdoor tempera‐
ture (1)
At full
load
TS °C 46 46 46 46
At partial
load
TS °C 52 52 52 52
ARH/ARD
Summer cycle
Temperature of air input in indoor coil
WB °C Min./Max. 15/23 15/23 15/23 14/23
DB °C Min./Max. 20/32 20/32 20/32 20/32
Outdoor temperature (without condensa‐
tion control)
TS °C Min. 7 7 7 7
Maximum outdoor tempera‐
ture (1)
At full
load
TS °C 46 46 46 46
At partial
load
TS °C 52 52 52 52
Winter cycle
Temperature of air input in indoor coil DB °C Min./Max. 10/25 10/25 10/25 10/25
Outdoor temperature DB °C Min./Max. -10/20 -10/20 -10/20 -10/20
ARG/ARD (2) Gas heating
Indoor temperature TS °C Max 30 30 30 30
Outdoor temperature DB °C Min./Max. -15/25 -15/25 -15/25 -15/25
1. Direct sunlight on the unit should be prevented when temperatures are higher than 43ºC. If placed under some kind of protective cover, the cover should not interfere
with the flow of outdoor ventilation.
2. The gas heating units (ARG/ARD) are only appropriate for use with gas. In LPG (Liquefied Petroleum Gas, propane) installations, it must be ensured that in no case
should gasoline in liquid form reach the gas group.
DB: Dry-bulb Thermometer; TH: Wet-bulb thermometer.
1.8 Power and application data for gas ARG / ARD
Model
Heat capacity Gas consumption m
3
/h
Temperature rise in ºC at full
power (4)
Total (LHV) (1) kW Net kW
Natural gas (2) L.P.G. pro‐
pane (3)
Standard High power Standard High power Standard High power
Optional (on‐
ly standard)
Min. Max.
045 85 100 76 90 8,6 9,8 3,6 17 33
060 85 100 76 90 8,6 9,8 3,6 17 33
075 85 100 76 90 8,6 9,8 3,6 17 33
090 85 100 76 90 8,6 9,8 3,6 17 33
(1) LHV: Lower heating value.
(2) Natural gas 2ND-H, G20, at 20 mbar and 15 ºC
(3) Propane gas, G31, at 37 mbar and 15 ºC.
(4) The air flow should be regulated so as to increase temperature within the specified limits. Units with optional high power burners should have a minimum air flow of
10000 m
3
/h.
Note: The gas units are shipped ready to operate with natural gas. A conversion kit can be used to convert them to propane gas (L.P.G.).
