York ARC 045 - Output Table for Indoor Fan, Model ARC-045, Applications with Side Ducts, Standard Drive Motor 3 Kw; Performance Table for Inside Fan, Model ARC-045, Applications with Side Ducts, Optional Operation HPD Motor 4 Kw; Output Table for Indoor Fan, Model ARC-060, Applications with Side Ducts, Standard Drive Motor 4 Kw

C A U T I O N
Before consulting the tables, add secure drops to the pressure required for the installation due to:
• heat pump (models ARH/ARD-045 and 060)
• Gas heating (ARG/ARD Models)
• vertical supply and return and
• accessories included in the unit, when appropriate. See Pressure drop of options/accessories, gas
heating and vertical ducts. , see on page 21 .
The motor pulleys come adjusted to an opening of 4 turns. See Maintenance tasks performed by spe‐
cialised personnel
, see on page 35 for the belt adjustment and tightening procedure.
C A U T I O N
• Before commissioning the installation, but after balancing the air distribution in the building, the supply
air flow should be checked.
• With clean filters the indoor fan should not exceed a -200 Pa drop in intake.
1.13.3 Output table for indoor fan, model ARC-045, applications with side
ducts, standard drive motor 3 kW
Motor pulley open‐
ing adjustment
(no. of turns)
Air flow m
3
/h
7000 8000 8500 9000 10000
SPA kW SPA kW SPA kW SPA kW SPA kW
0 244 1,9 203 2,1 182 2,2 160 2,4 114 2,7
1 220 1,8 185 2,0 155 2,1 134 2,3 85 2,6
2 194 1,7 167 1,9 130 2 106 2,1 53 2,4
3 174 1,6 138 1,8 106 1,9 80 2 - -
4 152 1,4 108 1,6 82 1,8 54 1,9 - -
5 122 1,3 80 1,5 52 1,6 - - - -
6 94 1,1 52 1,4 - - - - - -
SPA: Static pressure available (Pa).
1.13.4 Performance table for inside fan, model ARC-045, applications with
side ducts, optional operation HPD motor 4 kW
Motor pulley opening
adjustment (no. of
turns)
Air flow m
3
/h
7000 8000 8500 9000 10000
PED kW PED kW PED kW PED kW PED kW
0 425 2,8 392 3,2 368 3,3 346 3,5 298 3,9
1 380 2,8 342 3,1 320 3,3 297 3,5 244 3,8
2 338 2,7 294 3,0 268 3,2 247 3,4 187 3,7
3 310 2,6 270 2,9 246 3,0 225 3,2 168 3,5
4 280 2,4 248 2,7 224 2,8 202 3,0 147 3,3
5 245 2,3 212 2,6 188 2,7 165 2,9 110 3,2
6 212 2,2 175 2,5 150 2,6 126 2,7 70 3,0
PED: Static pressure available (Pa).
1.13.5 Output table for indoor fan, model ARC-060, applications with side
ducts, standard drive motor 4 kW
Motor pulley open‐
ing adjustment
(no. of turns)
Air flow m
3
/h
9500 10500 11500 12500 13500
PED kW PED kW PED kW PED kW PED kW
0 340 3,2 308 3,5 270 3,9 230* 4,3* 176* 4,5*
1 310 3,1 277 3,4 240 3,7 197* 4,1* 146* 4,4*
2 280 2,9 248 3,2 210 3,5 163 3,9 115* 4,3*
3 250 2,7 220 3,0 180 3,3 147 3,7 88* 4,1*
4 218 2,5 188 2,8 152 3,1 130 3,5 60 3,9
