York ARC 045 - ARH;ARD Output; ARH;ARD 045 Cooling Capacities; ARH;ARD 060 Cooling Capacities

* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
1.12 ARH/ARD Output
1.12.1 ARH/ARD 045 Cooling capacities
Return air Outdoor coil air temperature (TS)
Flow
m
3
/h
TH
ºC
27 ºC 35 ºC 46 ºC
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
Input temp. TS in indoor coil Input temp. TS in indoor coil Input temp. TS in indoor coil
30 27 24 22 30 27 24 22 30 27 24 22
(Mini‐
mum)
7000
23 53.7 11.1 31.8 25.2 18.6 - 50.9 12.2 30.8 41.3 17.6 - 45.9 13.5 29.2 22.6 16 -
19 48.6 10.8 41.7 35.1 28.5 24.1 45.9 11.7 40.6 24.2 27.4 23 41.3 12.6 39 32.3 25.7 21.3
17 45.9 10.5 45.9 40 33.3 32.5 42.2 11.6 42.2 34 31.6 29.2 37.6 12.5 37.6 36.3 29.8 25.4
15 41.3 10.4 41.3 41.3 36.9 32.5 39.5 11.3 39.5 38.2 36 31.6 35.3 12.4 35.3 35.3 34.2 29.8
(Nominal)
8500
23 55.7 11.3 34.9 27.1 19.2 - 52.8 12.4 33.9 26.1 18.3 - 47.6 13.7 32.3 24.5 16.6 -
19 50.5 10.9 46.6 38.8 30.9 25.7 47.6* 11.9* 45.5 37.6* 29.8 24.6 42.8 12.9 42.8 35.9 28.1 22.9
17 47.6 10.7 47.6 44.5 36.6 36.8 43.8 11.8 43.8 42.7 34.9 32.4 39 12.7 39 39 33 27.8
15 42.8 10.6 42.8 42.8 41.1 35.9 40.9 11.5 40.9 40.9 40.1 34.9 36.7 12.6 36.7 36.7 36.7 33.1
(Maxi‐
mum)
10000
23 57.25 11.5 37.9 28.9 19.8 - 54.3 12.6 37 27.9 18.8 - 48.9 213.9 35.3 26.3 17.2 -
19 51.8 11.1 51.3 42.2 33.2 27.2 48.9 12.1 48.9 41.1 32.1 26 44 13.1 44 39.4 30.3 24.3
17 48.9 10.9 48.9 48.8 39.7 41.3 45 12 45 45 37.9 35.6 40.1 12.9 40.1 40.1 36.1 30
15 44 10.8 44 44 44 39 42.1 11.7 42.1 42.1 42.1 38 37.6 12.8 37.6 37.6 37.6 36.2
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
1.12.2 ARH/ARD 060 Cooling capacities
Return air Outdoor coil air temperature (TS)
Flow
m
3
/h
TH
ºC
27 ºC 35 ºC 46 ºC
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
Input temp. TS in indoor coil Input temp. TS in indoor coil Input temp. TS in indoor coil
30 27 24 22 30 27 24 22 30 27 24 22
(Mini‐
mum)
9500
23 69.8 14.2 42.2 33.1 24.1 - 66.3 15.5 40.9 31.9 22.8 - 59.7 17.1 38.8 29.8 20.7 -
19 63.2 13.7 55.7 46.7 37.7 31.6 59.7 14.9 54.3 45.2 36.3 30.2 53.7 16.1 52.1 43 34 28
17 59.7 13.4 59.7 53.3 44.3 42.5 54.9 14.8 54.9 51 42 38.3 48.9 15.9 49 48.7 36.7 33.6
15 53.7 13.3 53.7 53.7 49.3 43.3 51.3 14.5 51.3 51.3 48 42 46 15.8 46 46 45.8 39.8
(Nomi‐
nal)
11500
23 72.4 14.4 46.5 35.8 25 - 68.7 15.8 45.2 34.5 23.8 - 61.9 17.5 43.2 32.4 21.7 -
19 65.6 14 62.4 51.7 41 33.8 61.9* 15.2* 61 50.3* 39.5 32.4 55.7 16.4 55.7 48 37.3 30.1
17 61.9 13.7 61.9 59.5 48.7 48.1 56.9 15 56.9 56.9 46.5 42.5 50.8 16.3 50.8 50.8 44.1 36.9
15 55.7 13.5 55.7 55.7 55 47.8 53.2 14.7 53.2 53.2 53.2 46.5 47.7 16.1 47.7 47.7 47.7 44.2
(Maxi‐
mum)
13500
23 74.4 14.6 50.7 38.2 25.8 - 70.6 16 49.4 37 24.6 - 63.6 17.7 47.3 34.9 22.5 -
19 67.4 14.2 67.4 56.5 44.1 35.8 63.6 15.4 63.6 55.1 42.6 34.3 57.2 16.6 57.2 52.8 40.2 32.1
17 63.6 13.9 63.6 63.6 53 53 58.5 15.2 58.5 58.5 50.8 46.6 52.1 16.5 52.1 52.1 48.3 40
15 57.2 13.7 57.2 57.2 57.2 52.1 54.7 14.9 54.7 54.7 54.7 50.8 49 16.3 49 49 49 48.6
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
Installation manual 1
ARH/ARD Output 1.12
15
