1.13.9 Output table for indoor fan, model ARC/ARH-090, applications with
side ducts, standard drive motor 7.5 kW and optional HPD motor 9.2 kW.
Motor pulley
opening adjust‐
ment (no. of
turns)
Air flow m
3
/h
13000 14000 15000 16000 17000 18000
PED kW PED kW PED kW PED kW PED kW PED kW
0 480 6,9 420 7,5 368 7,9 314* 8,3* 250* 9,1* 180* 9,8*
1 435 6,5 380 7,1 322 7,5 265* 8,0* 205* 8,7* 136* 9,5*
2 390 6,1 335 6,6 276 7,0 218* 7,7* 160* 8,3* 93** 9,1**
3 352 5,6 298 6,1 245 6,5 184 7,1 120* 7,8* 55** 8,5**
4 316 5,1 262 5,5 212 6,0 150 6,6 78 7,3 - -
5 270 4,9 215 5,3 167 5,8 105 6,4 35 7,0 - -
6 225 4,7 172 5,1 120 5,7 60 6,2 - - - -
PED: Static pressure available (Pa).
* Optional Zone HPD motor 9,2 kW
** Zone outside of range
1.13.10 Output table for indoor fan, model ARC/ARH-090, applications with
side ducts, optional HPD drive motor 11 kW
Motor pulley
opening adjust‐
ment (no. of
turns)
Air flow m
3
/h
13000 14000 15000 16000 17000 18000
SPA kW SPA kW SPA kW SPA kW SPA kW SPA kW
0 -* -* -* -* 535 8,4 465 9,0 398 9,7 330 10,5
1 610 7,5 550 7,9 472 8,3 408 8,9 343 9,6 275 10,4
2 540 7,3 474 7,7 412 8,1 352 8,7 288 9,4 220 10,2
3 494 6,9 434 7,4 375 7,9 315 8,4 254 9,1 185 9,9
4 447 6,5 395 7,0 338 7,6 278 8,1 220 8,8 150 9,6
5 396 6,2 344 6,7 285 7,2 227 7,8 168 8,4 98 9,2
6 345 5,9 292 6,3 236 6,8 176 7,4 115 8,0 45 8,7
SPA: Static pressure available (Pa).
* Zone outside of range
1.14 Pressure drop of options/accessories, gas heating and ver‐
tical ducts.
Model m
3
/h (x 1000)
Pressure drop (Pa)
7 8 9 10 11 12 13 14 15 16 17 18
Gas heating ARG/ARD 18 20 24 30 37 45 53 60 70 80 90 100
Heat pump
ARH/ARD 045 8 13 14 17
ARH/ARD 060 18 22 26 30 34 36
Vertical supply
045/060 28 32 38 45 56 70 82 93
075/090 28 30 35 45 57 85 125 165
Vertical return 12 12 12 12 12 12 12 12 12 12 12 12
Option or accessory
Economiser / Motorised damper
7 9 11 13 16 19 22 25 29 33 37 43
Electric resistor
kW
12-25 20 28 36 44 56 68 80 92 110 125 144 170
37 28 37 46 56 70 85 100 114 130 150 172 194
50 45 60 75 92 110 130 155 180 210 240 274 310
Water coil 35 43 52 63 76 90 104 119 133 147 163 190
Air filters (F6)
045/060 50 55 65 70 75 87 100 114
075 55 65 68 70 82 87
090 78 80 92 97 110 118
Air filters (F7)
045/060 67 75 85 95 105 115 125 135
075 75 85 90 95 107 115
090 100 105 117 125 135 145
