1.9 Hot water coil, optional in ARC/ARH
ARC/ARH
Data with water, without glycol
090
075
060
045
Water temperature ºC 90 ÷ 70
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 17000 18000
Heat capacity kW 71,1 79,5 87,0 93,7 101,7 107,3 111 114,2 117,4
Water flow m
3
/h 3 3,3 3,7 4 4,3 4,5 4,7 4,8 5
Pressure drop kPa 9,5 11 14 16 19 21 22 23 25
Air temperature rise K 30 27 25 24 22 21 20 19 18
Water temperature ºC 80 ÷ 60
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 17000 18000
Heat capacity kW 58,6 65,4 71,5 77 83,5 88,1 90,8 93,7 96,3
Water flow m
3
/h 2,5 2,8 3 3,3 3,5 3,7 3,9 4 4,1
Pressure drop kPa 7,5 9 9,5 11 13 14 16 16 18
Air temperature rise K 24 22 21 20 18 17 17 16 15
Water temperature ºC 70 ÷ 50
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 17000 18000
Heat capacity kW 46,0 51,2 55,8 61,1 65,1 68,7 71 73 75
Water flow m
3
/h 1,9 2,2 2,4 2,6 2,8 2,9 3 3,1 3,2
Pressure drop kPa 4,5 6 6,5 7,5 9 9,5 10,5 11 11
Air temperature rise K 19 18 16 15 14 13 13 12 12
- Pressure drop of coil + 3-way valve.
- Coil input air: 18 ℃.
- Total volume of water in circuit 10 l.
- See air pressure drop,
Pressure drop of options/accessories, gas heating and vertical ducts. , see on page 21 .
ARC/ARH
Data with a mix of water and 35% glycol
090
075
060
045
Water temperature ºC 90 ÷ 70
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 17000 18000
Heat capacity kW 68,5 76,3 83,6 89,8 97,5 102,8 106,3 109,4 112,4
Water flow m
3
/h 3,2 3,6 4 4,2 4,6 4,8 5 5,1 5,3
Pressure drop kPa 12 15 17 20 23 25 27 28 30
Air temperature rise K 28 26 24 22 21 20 19 18 17
Water temperature ºC 80 ÷ 60
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 17000 18000
Heat capacity kW 55,6 62 67,7 72,8 79 83,3 85,9 88,5 91
Water flow m
3
/h 2,6 2,9 3,2 3,5 3,7 4 4,1 4,2 4,3
Pressure drop kPa 9 10 12 14 16 18 19 20 21
Air temperature rise K 23 21 20 18 17 16 16 15 14
Water temperature ºC 70 ÷ 50
Air flow m
3
7000 8500 10000 11500 13500 15000 16000 1700 18000
Heat capacity kW 41,4 46 50,7 54,8 59,6 63,1 65,3 67,3 69,2
Water flow m
3
/h 2 2,2 2,4 2,6 2,8 3 3,1 3,2 3,3
Pressure drop kPa 6 6,5 7 8,5 10 11 12 13 14
Air temperature rise K 17 16 15 14 13 12 12 11 11
- Pressure drop of coil + 3-way valve.
- Coil input air: 18 ℃.
- Total volume of water in circuit 10 l.
- See air pressure drop,
Pressure drop of options/accessories, gas heating and vertical ducts. , see on page 21 .
Installation manual 1
Hot water coil, optional in ARC/ARH 1.9
