Motor pulley open‐
ing adjustment
(no. of turns)
Air flow m
3
/h
9500 10500 11500 12500 13500
PED kW PED kW PED kW PED kW PED kW
5 190 2,3 162 2,6 123 3,0 90 3,4 30 3,7
6 160 2,1 134 2,4 92 2,8 50 3,2 - -
PED: Static pressure available (Pa).
* Zone outside of range
1.13.6 Output table for indoor fan, model ARC-060, applications with side
ducts, optional HPD drive motor 5.5 kW
Motor pulley opening
adjustment (no. of
turns)
Air flow m
3
/h
9500 10500 11500 12500 13500
PED kW PED kW PED kW PED kW PED kW
0 505 3,7 472 4,1 430 4,6 390 5,0 347* 5,7*
1 475 3,5 440 3,9 400 4,3 357 4,8 310 5,5
2 447 3,4 410 3,5 370 4,2 323 4,6 273 5,2
3 418 3,2 380 3,4 340 3,9 292 4,4 245 4,9
4 387 3,0 350 3,2 307 3,7 260 4,1 215 4,5
5 340 2,9 306 3,1 267 3,5 223 3,9 178 4,3
6 295 2,7 262 3,0 227 3,3 185 3,7 140 4,1
PED: Static pressure available (Pa).
* Zone outside of range
1.13.7 Output table for indoor fan, model ARC-075, applications with side
ducts, standard drive motor 5.5 kW
Motor pulley open‐
ing adjustment
(no. of turns)
Air flow m
3
/h
11500 12500 13500 14500 15000 16000
PED kW PED kW PED kW PED kW PED kW PED kW
0 335 3,9 294 4,3 240 4,7 195 5,1 143 5,4 105* 5,8*
1 280 3,6 240 4,0 190 4,4 140 4,8 108 5,1 45 5,5
2 226 3,3 187 3,8 140 4,1 85 4,5 50 4,8 - -
3 190 3,1 148 3,5 104 3,8 25 4,2 - - - -
4 155 2,9 116 3,2 43 3,6 - - - - - -
5 124 2,8 78 3,1 - - - - - - - -
6 97 2,7 40 3,0 - - - - - - - -
PED: Static pressure available (Pa).
* Zone outside of range
1.13.8 Performance table for inside fan, model ARC/ARH-075, applications
with side ducts, optional operation HPD motor 7.5 kW
Motor pulley open‐
ing adjustment
(no. of turns)
Air flow m
3
/h
11500 12500 13500 14500 15000 16000
PED kW PED kW PED kW PED kW PED kW PED kW
0 -* -* -* -* -* -* -* -* 625* 8,2* 540* 8,8*
1 -* -* -* -* -* -* 595 7,4 564* 8,0* 508* 8,6*
2 660 5,1 630 5,9 588 6,5 540 7,2 512* 7,7* 460* 8,4*
3 610 4,9 565 5,5 524 6,1 478 6,8 450 7,3 400* 7,9*
4 550 4,7 510 5,2 465 5,8 420 6,5 394 6,9 338 7,5
5 495 4,5 450 5,0 408 5,5 362 6,1 330 6,5 277 7,0
6 440 4,3 400 4,8 352 5,3 305 5,8 273 6,1 220 6,6
* Zone outside of range
