Return air Outdoor coil air temperature (TS)
Flow
m
3
/h
TH
ºC
27 ºC 35 ºC 46 ºC
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
Input temp. TS in indoor coil Input temp. TS in indoor coil Input temp. TS in indoor coil
30 27 24 22 30 27 24 22 30 27 24 22
17 61 14.1 61 58 47.6 49.8 56.1 15.5 56.1 55.7 45.3 43 50 16.8 50 50 43 36.1
15 54.9 14 54.9 54.9 53.5 46.6 52.5 15.2 52.5 52.5 52.3 45.3 47 16.6 47 47 47 43.1
(Maxi‐
mum)
13500
23 73.2 15.1 49.3 37.3 25.4 - 69.5 16.5 48.1 36.1 24.1 - 62.6 18.3 46 34 22.1 -
19 66.4 14.6 66.4 55 43 35 62.6 15.9 62.6 53.5 41.6 33.6 56.3 17.2 56.3 51.4 39.4 31.4
17 62.6 14.3 62.6 62.6 51.6 56 57.8 15.7 57.8 57.6 49.4 47.2 51.3 17 51.3 51.3 47 39
15 56.3 14.2 56.3 56.3 56.3 50.7 53.8 15.4 53.8 53.8 53.8 49.4 48.2 16.9 48.2 48.2 48.2 47.2
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
1.11.3 ARC/ARG 075 Cooling capacities
Return air Outdoor coil air temperature (TS)
Flow
m
3
/h
TH
ºC
27 ºC 35 ºC 46 ºC
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
Input temp. TS in indoor coil Input temp. TS in indoor coil Input temp. TS in indoor coil
30 27 24 22 30 27 24 22 30 27 24 22
(Mini‐
mum)
11500
23 81.2 19.5 49.3 38.7 28 - 77 21.3 47.8 37.2 26.6 - 69.4 23.6 45.4 34.8 24.2 -
19 73.6 18.9 65.2 54.6 44 36.9 69.4 20.5 63.5 52.9 42.3 35.2 62.5 22.1 61 50.4 39.7 32.7
17 69.4 18.5 69.4 62.6 51.7 52 63.8 20.3 63.8 59.8 49.1 46 56.9 21.9 56.9 56.9 46.4 39.3
15 62.5 18.2 62.5 62.5 57.6 50.6 59.7 19.9 59.7 59.7 56.1 49.1 53.4 21.7 53.4 53.4 53.4 46.5
(Nominal)
13500
23 83.7 19.9 53.4 41.1 28.9 - 79.4 21.7 51.9 39.7 27.4 - 71.5 24 49.5 37.3 25 -
19 75.8 19.2 71.6 59.3 47.1 38.9 71.5* 20.9* 70 57.7* 45.4 37.2 64.3 22.6 64.3 55.1 42.8 34.7
17 71.5 18.8 71.5 68.2 56 58.1 65.8 20.7 65.8 65.6 53.3 50.3 58.6 22.4 58.6 58.6 50.6 42.4
15 64.3 18.6 64.3 64.3 63 54.9 61.5 20.3 61.5 61.5 61.5 53.4 55 22.2 55 55 55 50.8
(Maxi‐
mum)
16000
23 86 20.1 58.3 44.1 29.8 - 81.6 22 56.9 42.6 28.3 - 73.5 24.4 63.2 40.2 25.9 -
19 78 19.5 78 65 50.8 41.3 73.5 21.2 73.5 63.3 49.1 39.6 66.2 22.9 54.4 60.8 46.5 37
17 73.5 19.1 73.5 73.5 61 65.6 67.6 21 67.6 67.6 58.4 55.5 60.3 22.7 66.2 60.3 55.6 46.1
15 66.2 18.9 66.2 66.2 66.2 60 63.2 20.6 63.2 63.2 63.2 58.5 56.6 22.5 60.3 56.6 56.6 55.8
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
1.11.4 ARC/ARG 090 Cooling capacities
Return air Outdoor coil air temperature (TS)
Flow
m
3
/h
TH
ºC
27 ºC 35 ºC 46 ºC
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
Input temp. TS in indoor coil Input temp. TS in indoor coil Input temp. TS in indoor coil
30 27 24 22 30 27 24 22 30 27 24 22
(Mini‐
mum)
13000
23 94.5 19.5 57.8 45.2 32.6 - 89.7 21.3 56.2 43.6 31 - 80.8 23.6 53.4 40.8 28.2 -
19 85.6 18.9 76.7 64.1 51.5 43.1 80.8 20.5 74.8 62.2 49.6 41.1 72.7 22.1 71.8 59.2 46.6 38.2
17 80.8 18.5 80.8 73.3 60.7 56.2 74.3 20.3 74.3 70.3 57.7 51.4 66.3 21.9 66.3 66.3 54.5 46.1
15 72.7 18.2 72.7 72.7 67.8 59.4 69.5 19.9 69.5 69.5 66.1 57.7 62.2 21.7 62.2 62.2 62.2 54.7
(Nominal)
16000
23 98.2 22.8 64.6 49.3 34 - 93.2 25 62.9 47.6 32.3 - 84 27.6 60.1 44.8 29.5 -
19 89 22.1 87.3 71.9 56.6 46.4 84* 24* 84 70* 54.7 44.5 75.6 25.9 75.6 67 51.7 41.5
17 84 21.6 84 83 67.7 63.8 77.3 23.8 77.3 77.3 64.6 57.5 68.9 25.7 68.9 68.9 61.4 51.2
15 75.6 21.4 75.6 75.6 75.6 66.4 72.2 23.3 72.2 72.2 72.2 64.7 64.7 25.4 64.7 64.7 64.7 61.7
(Maxi‐
mum)
18000
23 100 23.1 68.9 51.8 34.7 - 95 25.3 67.3 50.2 33.1 - 85.6 27.9 64.5 47.4 30.3 -
19 90.7 22.4 90.7 77 60 48.5 85.6 24.3 85.6 75 57.9 46.5 77 26.2 77 72 54.9 43.5
17 85.6 21.9 85.6 85.6 72.2 68.9 78.8 24.1 78.8 78.7 69.1 61.4 70.2 26 70.2 70.2 65.9 54.5
15 77 21.6 77 77 77 71 73.6 23.6 73.6 73.6 73.6 69.2 66 25.8 66 66 66 66
1 Installation manual
1.11 ARC/ARG Performance
14
