Models ARC/ARG 045 060 075 090
Maximum static pressure with rated flow
(standard)
Pa 182 270 240 368
Maximum static pressure with rated flow
(optional HPD drive)
Pa 368 430 >500 >500
Maximum flow m
3
/h 10000 13500 16000 18000
Minimum flow m
3
/h 7000 9500 11500 13000
IP55 Motor (standard) kW 3 4 5,5 7,5
Rated current A 5,5 5,7 7,6 11,7
IP55 Motor (HPD optional) kW 4 5,5 7,5 9,2/11
Rated current A 5,7 7,6 11,7 14/17,4
Indoor coil (evaporator)
Number of elements No. 2 3 3 4
Distance between fins mm 1,81 1,81 1,81 1,81
Front surface m
2
1,44 1,58 1,95 1,06 (x 2)
Air filters (G4)
Quantity per unit No. 6 6
Dimensions mm 470x550x48 565x594x48
Outdoor fan
Diameter / number mm 800/1 800/2 800/2 800/2
Total rated flow m
3
/h 15000 23000 27000 27000
Motor (IP54) kW 1,9 1,9 1,9 1,9
Rated current A 3,5 2x3,5 2x3,5 2x3,5
Outdoor coil (condens‐
er)
Number of elements No. 2 3 2 3
Distance between fins mm 1,81 1,81 1,81 1,81
Front area m
2
2,27 2,49 2.31 (x2) 2.31 (x2)
Net dimensions (4)
Height mm 1316 1367
Length mm 3180 3495
Width mm 2337 2337
Net weight (basic unit
without accessories) (4)
ARC kg 900 945 1118 1142
ARG kg 1010 1055 1228 1252
Electrical features of
the unit
Total rated power kW 16 23 30 36
Total rated current A 32 42 54 70
Total maximum power kW 23 31 38 45
Total maximum current A 42 56 70 83
Circuit breaker (K Curve (5) A 50 63 80 100
Minimum cable section (6) mm
2
10 16 25 35
(1) Data comply with Eurovent conditions, summer: indoor 27 °C TS / 19 °C TH - outdoor TS 35 °C (TS Dry-bulb Thermometer; TH Wet-bulb thermometer).
(2) Add the inside motor consumption to find the total calorific capacity.
(3) See
Indoor fan
, see on page 18
.
(4) Consider the additional weight of options and accessories. To do so, see
Weight options and accessories
, see on page 7
.
LHV: Lower heating value.
(5) and (6) Circuit breaker with K curve, according to DIN, VDE 0660-104. Section of cables for the power supply line based on copper conductors, 105 ºC. The indicated
circuit breaker and the section of power supply cables are guidelines. They should be adjusted based on the requirements of each installation, distance between units, fall
in planned voltage and on the application of the current regulations with respect to the country where the unit is being installed.
1.4.2 ARH technical and physical data (heat pump) and ARD (heat pump
+ gas heat)
Models ARH/ARD 045 060 075 090
Cooling capacity(1)
Net cooling capacity kW 47,6 61,9 71,4 83,4
Rated absorbed power in cool
mode
kW 17 20 28 36
Heat capacity
Heating capacity (2) kW 45,2 58 71,7 86,5
Rated power absorbed in heat
mode
kW 16 19 27 33
Optional electric heating ca‐
pacity (400 V) (ARH) (2)
kW 12-25-37-50
Gas Heating (ARG)
Heat capacity at 100% power
(standard)
(LHV) Total kW 85
Net (2) kW 76
Heat capacity at 100% power,
high capacity (optional)
Total kW 100
Installation manual 1
Technical data 1.4
5
