Air temperature
Mode (cool or heat): Temperature (ºC)
Outdoor air:
Supply air:
Return air:
Indoor air mix (if economiser is fitted):
OPTIONS
Heating mode (hot water coil)
Air temperature
Capacity: _____ (kW) Temperature (ºC)
Supply air (at 100 %)
Return air
Hydraulic circuit
Temperature (ºC) Pressure (bar)
Water inlet
Water outlet
Heating mode (gas burner) (ARG/ARD models)
Air temperature
Capacity: _____ (kW) Temperature (ºC)
Supply air (at 100 %)
Return air
Gas circuit (Natural gas)
Gas family G20
Pressure (mbar)
G25
Supply line Min. 12.5 / Max. 25 mbar
Gas valve adjustments
Main regulator (PBr)
Stage regulator (V
max
)
Gas consumption m
3
/h
Propane gas conversion, G31, if applicable
Supply line 37 mbar
Pressure mbar
Gas valve adjustments
Main regulator
Stage regulator
Gas consumption m
3
/h
Combustion analyser
Outdoor ambient temperature ___ ºC
Smoke temperature ___ ºC
Carbon monoxide CO content ____ ppm or ___ %
Carbon dioxide content CO
2
___ %
Nitrogen oxide content NO ____ ppm
2 Unit installation data
2.2 Start-up Data
