York MILLENNIUM Y24 - Hot Water Coil - 40 Ton, 1 Row, at 10 Gpm; Hot Water Coil - 40 Ton, 1 Row, at 20 Gpm

102777-YIM-E-0206
Unitary Products Group 121
FIGURE 42 - HOT WATER COIL - 40 TON, 1 ROW, AT 10 GPM
90.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
8000 9000 10000 11000 12000 13000 14000 15000 16000 17000 18000 19000 20000
FLOW RATE (CFM)
CAPACITY (MBH)
140 °F
160 °F
180 °F
200 °F
FIGURE 43 - HOT WATER COIL - 40 TON, 1 ROW, AT 20 GPM
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
270.0
280.0
290.0
300.0
8000 9000 10000 11000 12000 13000 14000 15000 16000 17000 18000 19000 20000
FLOW RATE (CFM)
CAPACITY (MBH)
140 °F
160 °F
180 °F
200 °F
