York MILLENNIUM Y24 - Electrical Data Basic Unit - 30 Ton; Electrical Data Basic Unit - 40 Ton

102777-YIM-E-0206
Unitary Products Group 23
TABLE 14: ELECTRICAL DATA BASIC UNIT - 30 TON
VOLTAGE
COMPRESSORS COND. FAN MOTOR SUPPLY AIR MOTOR BASIC UNIT
QTY. RLA LRA QTY. FLA TOTAL HP FLA MCA
MAX. OVERCURRENT
PROTECTION DEVICE
208-3-60 3 38.5 228 3 4.0 ea. 12.0
10 30.8 168 200
15 46.2 185 225
20 59.4 202 250
25 74.8 221 250
230-3-60 3 38.5 255 3 3.6 ea. 10.8
10 28 164 200
15 42 179 200
20 54 194 225
25 68 211 250
460-3-60 3 18.8 127 3 2.2 ea. 6.6
10 14 81 90
15 21 88 100
20 27 96 110
25 34 104 125
575-3-60 3 15.7 100 3 1.4 ea. 4.2
10 11 66 80
15 17 73 80
20 22 79 100
25 27 85 110
TABLE 15: ELECTRICAL DATA BASIC UNIT - 40 TON
VOLTAGE
COMPRESSORS COND. FAN MOTOR SUPPLY AIR MOTOR
BASIC UNIT OVERCURRENT
PROTECTION DEVICE
QTY. RLA LRA QTY. FLA TOTAL HP FLA MCA
MAX. OVERCURRENT
PROTECTION DEVICE
208-3-60 4 38.5 228 4 4.0 ea. 12.0
10 30.8 210 225
15 46.2 228 250
20 59.4 244 300
25 74.8 264 300
230-3-60 4 38.5 255 4 3.6 ea. 14.4
10 28 206 225
15 42 221 250
20 54 236 250
25 68 253 300
460-3-60 4 18.8 127 4 2.2 ea. 8.8
10 14 101 110
15 21 109 125
20 27 116 125
25 34 125 150
575-3-60 4 15.7 100 4 1.4 ea. 5.6
10 11 83 90
15 17 90 100
20 22 96 110
25 27 102 125
