York Sun Select YV28 - Electrical Data; Constant Volume Standard Static

Electrical data
Constant volume standard static
Note:
• MCA = minimum circuit ampacity
• f/b = fuse/breaker
• Fuse is a dual element, time delay type
• Breaker is a HACR type per NEC
Table 9: YV28 to YV50 Constant volume standard static without power exhaust
Comp. 1 Comp. 2
Min
disconnect
rating
Min
disconnect
rating/120V
trans
Size
(tons)
Nominal
unit
voltage
RLA LRA RLA LRA
OD fan
motors
each
FLA
OD fan
motors
each
LRA
Supply
blower
motor
FLA
Supply
blower
motor
LRA
120 V
trans
FLA
MCA
A
Max
f/b
size
A
FLA LRA
MCA
with
120 V
trans
A
Max
f/b
size
with
120V
trans
A
FLA LRA
208-3-60 41.0 304 41.0 304 4.0 21.0 19.4 144.4 14.4 128 150 135 836.4 142 175 151.6 850.8
230-3-60 41.0 304 41.0 304 4.2 21.0 19.4 144.4 13.0 128 150 136 836.4 141 175 150.9 849.4
460-3-60 19.2 147 19.2 147 2.1 10.5 9.7 72.2 6.5 61 80 65 408.2 68 80 72.5 414.7
YV28
(27.5)
575-3-60 16.7 122 16.7 122 1.6 7.8 8.0 59.1 5.2 52 60 55 334.3 57 70 61.0 339.5
208-3-60 44.2 315 44.2 315 4.0 21.0 19.4 144.4 14.4 135 175 142 858.4 149 175 158.9 872.8
230-3-60 44.2 315 44.2 315 4.2 21.0 19.4 144.4 13.0 136 175 143 858.4 149 175 158.2 871.4
460-3-60 22.4 158 22.4 158 2.1 10.5 9.7 72.2 6.5 69 90 72 430.2 75 90 79.8 436.7
YV30
(30)
575-3-60 18.6 136 18.6 136 1.6 7.8 8.0 59.1 5.2 56 70 59 362.3 61 80 65.3 367.5
208-3-60 48.1 351 48.1 351 4.0 21.0 19.4 144.4 14.4 144 175 151 930.4 158 200 167.9 944.8
230-3-60 48.1 351 48.1 351 4.2 21.0 19.4 144.4 13.0 144 175 152 930.4 157 200 167.2 943.4
460-3-60 24.7 197 24.7 197 2.1 10.5 9.7 72.2 6.5 74 90 78 508.2 80 100 85.1 514.7
YV35
(35)
575-3-60 22.4 135 22.4 135 1.6 7.8 8.0 59.1 5.2 65 80 68 360.3 70 90 74.1 365.5
208-3-60 48.1 351 48.1 351 4.0 21.0 25.0 173.44 14.4 149 175 158 959.4 164 200 174.3 973.8
230-3-60 48.1 351 48.1 351 4.2 21.0 25.0 173.44 13.0 150 175 159 959.4 163 200 173.7 972.4
460-3-60 24.7 197 24.7 197 2.1 10.5 12.5 86.72 6.5 76 100 81 522.7 83 100 88.3 529.2
YV40
(40)
575-3-60 22.4 135 22.4 135 1.6 7.8 10.0 71.77 5.2 67 80 70 373.0 72 90 76.4 378.2
208-3-60 67.3 485 67.3 485 7.2 39.6 25.0 173.44 14.4 205 250 217 1301.8 220 275 233.2 1316.2
230-3-60 67.3 485 67.3 485 6.8 39.6 25.0 173.44 13.0 204 250 215 1301.8 217 275 229.8 1314.8
460-3-60 32.7 215 32.7 215 3.4 19.8 12.5 86.72 6.5 100 125 105 595.9 106 125 112.7 602.4
YV50
(50)
575-3-60 26.3 175 26.3 175 2.7 15.8 10.0 71.77 5.2 80 100 84 485.0 85 110 90.4 490.2
Table 10: YV28 to YV50 Constant volume standard static with on/off power exhaust
Comp. 1 Comp. 2
Min
disconnect
rating
Min
disconnect
rating/120V
trans
Size
(tons)
Nominal
unit
voltage
RLA LRA RLA LRA
OD fan
motors
each
FLA
OD fan
motors
each
FLA
Supply
blower
motor
FLA
Supply
blower
motor
LRA
Power
exhaust
VFD FLA
Power
exhaust
motor
LRA
120 V
trans
FLA
MCA
A
Max
f/b
size
A
FLA LRA
MCA
with
120 V
trans
A
Max
f/b
size
with
120V
trans
A
FLA LRA
208-3-60 41.0 304 41.0 304 4.0 21.0 19.4 144.4 4.0 21.0 14.4 136 175 144 878 150 175 161 893
230-3-60 41.0 304 41.0 304 4.2 21.0 19.4 144.4 4.2 21.0 13.0 137 175 146 878 150 175 161 891
460-3-60 19.2 147 19.2 147 2.1 10.5 9.7 72.2 2.1 10.5 6.5 66 80 70 429 72 90 77 436
YV28
(27.5)
575-3-60 16.7 122 16.7 122 1.6 7.8 8.0 59.1 1.6 7.8 5.2 55 70 59 350 60 75 65 355
208-3-60 44.2 315 44.2 315 4.0 21.0 19.4 144.4 4.0 21.0 14.4 143 175 152 900 157 200 168 915
230-3-60 44.2 315 44.2 315 4.2 21.0 19.4 144.4 4.2 21.0 13.0 144 175 153 900 157 200 168 913
460-3-60 22.4 158 22.4 158 2.1 10.5 9.7 72.2 2.1 10.5 6.5 73 90 77 451 79 100 85 458
YV30
(30)
575-3-60 18.6 136 18.6 136 1.6 7.8 8.0 59.1 1.6 7.8 5.2 59 75 63 378 65 80 69 383
208-3-60 48.1 351 48.1 351 4.0 21.0 19.4 144.4 4 21.0 14.4 152 175 161 972 166 200 177 987
230-3-60 48.1 351 48.1 351 4.2 21.0 19.4 144.4 4.2 21.0 13.0 153 200 162 972 166 200 177 985
460-3-60 24.7 197 24.7 197 2.1 10.5 9.7 72.2 2.1 10.5 6.5 78 100 82 529 84 100 90 536
YV35
(35)
575-3-60 22.4 135 22.4 135 1.6 7.8 8.0 59.1 1.6 7.8 5.2 68 90 72 376 73 90 78 381
208-3-60 48.1 351 48.1 351 4.0 21.0 25.0 173.44 7.2 39.6 14.4 164 200 174 1039 178 225 191 1053
230-3-60 48.1 351 48.1 351 4.2 21.0 25.0 173.44 6.8 39.6 13.0 164 200 174 1039 177 200 189 1052
460-3-60 24.7 197 24.7 197 2.1 10.5 12.5 86.72 3.4 19.8 6.5 83 100 89 562 90 110 96 569
YV40
(40)
575-3-60 22.4 135 22.4 135 1.6 7.8 10.0 71.77 2.7 15.8 5.2 72 90 77 405 77 90 83 410
