Table 35: YV28 to YV50 VFD four-stage high static with modulating power exhaust
Comp. 1 Comp. 2 Comp. 3
Min
disconnect
rating
Min
disconnect
rating/120V
trans
Size
(tons)
Nominal
unit
voltage
RLA LRA RLA LRA RLA LRA
OD fan
motors
each
FLA
OD fan
motors
each
FLA
Supply
blower
motor
FLA
Supply
blower
motor
LRA
Power
exhaus
t VFD
FLA
Power
exhaus
t motor
LRA
120 V
trans
FLA
MCA
A
Max
f/b
size
A
FLA LRA
MCA
with
120 V
trans
A
Max
f/b
size
with
120V
trans
A
FLA LRA
208-3-60 41.0 304 22.4 149 22.4 149 4.0 21.0 42.0 234 9.6 21.0 14.4 164 200 176 962 178 200 193 976
230-3-60 41.0 304 22.4 149 22.4 149 4.2 21.0 42.0 234 9.6 21.0 13.0 165 200 177 962 178 200 192 975
460-3-60 19.2 147 10.6 75 10.6 75 2.1 10.5 21.0 117 4.8 10.5 6.5 80 100 86 477 86 100 93 484
YV28
(27.5)
575-3-60 16.7 122 7.7 54 7.7 54 1.6 7.8 18.0 95.94 4.9 7.8 5.2 66 80 71 373 71 80 77 378
208-3-60 44.2 315 25 164 25 164 4.0 21.0 42.0 234 9.6 21.0 14.4 173 200 186 1003 187 225 203 1017
230-3-60 44.2 315 25 164 25 164 4.2 21.0 42.0 234 9.6 21.0 13.0 174 200 187 1003 187 225 202 1016
460-3-60 22.4 158 12.8 100 12.8 100 2.1 10.5 21.0 117 4.8 10.5 6.5 88 110 95 538 94 110 102 545
YV30
(30)
575-3-60 18.6 136 9.6 78 9.6 78 1.6 7.8 18.0 95.94 4.9 7.8 5.2 72 90 77 435 77 90 83 440
208-3-60 48.1 351 27.6 191 27.6 191 4.0 21.0 42.0 234 9.6 21.0 14.4 183 225 197 1093 197 225 213 1107
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 42.0 234 9.6 21.0 13.0 184 225 197 1093 197 225 212 1106
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 21.0 117 4.8 10.5 6.5 91 110 97 577 97 110 105 584
YV35
(35)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 18.0 95.94 4.9 7.8 5.2 77 90 82 434 82 100 88 439
208-3-60 48.1 351 27.6 191 27.6 191 4.0 21.0 59.4 312 15.2 39.6 14.4 209 250 223 1208 223 275 240 1223
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 59.4 312 15.2 39.6 13.0 210 250 224 1208 223 275 239 1221
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 27.0 156 8.2 19.8 6.5 101 125 108 635 107 125 115 641
YV40
(40)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 22.0 126 6.1 15.8 5.2 82 100 88 480 87 100 93 485
208-3-60 67.3 485 39.1 267 39.1 267 7.2 39.6 74.8 312 15.2 39.6 14.4 283 350 304 1569 297 350 321 1583
230-3-60 67.3 485 39.1 267 39.1 267 6.8 39.6 74.8 312 15.2 39.6 13.0 281 350 302 1569 294 350 317 1582
460-3-60 32.7 215 18.6 142 18.6 142 3.4 19.8 27.0 156 8.2 19.8 6.5 127 150 137 774 133 150 144 780
YV50
(50)
575-3-60 26.3 175 15.4 103 15.4 103 2.7 15.8 22.0 126 6.1 15.8 5.2 103 125 110 602 108 125 116 607
