Table 38: YV28 to YV50 VFD Customer supplied standard static with modulating power exhaust
Comp. 1 Comp. 2 Comp. 3
Min
disconnect
rating
Min
disconnect
rating/120V
trans
Size
(tons)
Nominal
unit
voltage
RLA LRA RLA LRA RLA LRA
OD fan
motors
each
FLA
OD fan
motors
each
FLA
Supply
blower
motor
FLA
Supply
blower
motor
LRA
Power
exh
VFD
FLA
Power
exh
motor
LRA
120 V
trans
FLA
MCA
A
Max
f/b
size
A
FLA LRA
MCA
with
120 V
trans
A
Max
f/b
size
with
120V
trans
A
FLA LRA
208-3-60 41.0 304 22.4 149 22.4 149 4.0 21.0 19.4 144.4 9.6 21.0 14.4 141 175 150 872 155 175 167 887
230-3-60 41.0 304 22.4 149 22.4 149 4.2 21.0 19.4 144.4 9.6 21.0 13.0 142 175 151 872 155 175 166 885
460-3-60 19.2 147 10.6 75 10.6 75 2.1 10.5 9.7 72.2 4.8 10.5 6.5 68 80 73 432 75 90 80 439
YV28
(27.5)
575-3-60 16.7 122 7.7 54 7.7 54 1.6 7.8 8.0 59.1 4.9 7.8 5.2 56 70 59 336 61 75 65 341
208-3-60 44.2 315 25 164 25 164 4.0 21.0 19.4 144.4 9.6 21.0 14.4 150 175 160 913 165 200 177 928
230-3-60 44.2 315 25 164 25 164 4.2 21.0 19.4 144.4 9.6 21.0 13.0 151 175 161 913 164 200 176 926
460-3-60 22.4 158 12.8 100 12.8 100 2.1 10.5 9.7 72.2 4.8 10.5 6.5 77 90 82 493 83 100 89 500
YV30
(30)
575-3-60 18.6 136 9.6 78 9.6 78 1.6 7.8 8.0 59.1 4.9 7.8 5.2 62 80 66 398 67 80 72 403
208-3-60 48.1 351 27.6 191 27.6 191 4 21.0 19.4 144.4 9.6 21.0 14.4 160 200 171 1003 175 200 187 1018
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 19.4 144.4 9.6 21.0 13.0 161 200 171 1003 174 200 186 1016
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 9.7 72.2 4.8 10.5 6.5 79 100 84 532 86 110 92 539
YV35
(35)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 8.0 59.1 4.9 7.8 5.2 67 80 70 397 72 90 76 402
208-3-60 48.1 351 27.6 191 27.6 191 4 21.0 25.0 173.44 15.2 39.6 14.4 172 200 183 1070 186 225 200 1084
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 25.0 173.44 15.2 39.6 13.0 172 200 184 1070 185 225 199 1083
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 12.5 86.72 8.2 19.8 6.5 86 110 91 565 92 110 99 572
YV40
(40)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 10.0 71.77 6.1 15.8 5.2 70 90 74 426 75 90 80 431
208-3-60 67.3 485 39.1 267 39.1 267 7.2 39.6 25.0 173.44 15.2 39.6 14.4 231 275 247 1430 246 300 263 1444
230-3-60 67.3 485 39.1 267 39.1 267 6.8 39.6 25.0 173.44 15.2 39.6 13.0 230 275 245 1430 243 300 260 1443
460-3-60 32.7 215 18.6 142 18.6 142 3.4 19.8 12.5 86.72 8.2 19.8 6.5 112 125 120 705 119 150 127 711
YV50
(50)
575-3-60 26.3 175 15.4 103 15.4 103 2.7 15.8 10.0 71.77 6.1 15.8 5.2 91 110 97 548 96 110 103 553
Installation Manual: YORK
®
Sun
™
Select YV28 to YV50
57
