Table 41: YV28 to YV50 VFD Customer supplied medium static with modulating power exhaust
Comp. 1 Comp. 2 Comp. 3
Min
disconnect
rating
Min
disconnect
rating/120V
trans
Size
(tons)
Nominal
unit
voltage
RLA LRA RLA LRA RLA LRA
OD fan
motors
each
FLA
OD fan
motors
each
FLA
Supply
blower
motor
FLA
Supply
blower
motor
LRA
Power
exhaus
t VFD
FLA
Power
exhaus
t motor
LRA
120 V
trans
FLA
MCA
A
Max
f/b
size
A
FLA LRA
MCA
with
120 V
trans
A
Max
f/b
size
with
120V
trans
A
FLA LRA
208-3-60 41.0 304 22.4 149 22.4 149 4.0 21.0 25.0 173.44 9.6 21.0 14.4 147 175 157 901 161 200 173 916
230-3-60 41.0 304 22.4 149 22.4 149 4.2 21.0 25.0 173.44 9.6 21.0 13.0 147 175 158 901 160 200 173 914
460-3-60 19.2 147 10.6 75 10.6 75 2.1 10.5 12.5 86.72 4.8 10.5 6.5 71 90 76 447 77 90 83 453
YV28
(27.5)
575-3-60 16.7 122 7.7 54 7.7 54 1.6 7.8 10.0 71.77 4.9 7.8 5.2 58 70 61 349 63 75 67 354
208-3-60 44.2 315 25 164 25 164 4.0 21.0 25.0 173.44 9.6 21.0 14.4 156 200 167 942 170 200 183 957
230-3-60 44.2 315 25 164 25 164 4.2 21.0 25.0 173.44 9.6 21.0 13.0 157 200 167 942 170 200 182 955
460-3-60 22.4 158 12.8 100 12.8 100 2.1 10.5 12.5 86.72 4.8 10.5 6.5 79 100 85 508 86 100 92 514
YV30
(30)
575-3-60 18.6 136 9.6 78 9.6 78 1.6 7.8 10.0 71.77 4.9 7.8 5.2 64 80 68 411 69 80 74 416
208-3-60 48.1 351 27.6 191 27.6 191 4 21.0 25.0 173.44 9.6 21.0 14.4 166 200 177 1032 180 225 194 1047
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 25.0 173.44 9.6 21.0 13.0 167 200 178 1032 180 225 193 1045
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 12.5 86.72 4.8 10.5 6.5 82 100 87 547 89 110 95 553
YV35
(35)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 10.0 71.77 4.9 7.8 5.2 69 90 72 410 74 90 78 415
208-3-60 48.1 351 27.6 191 27.6 191 4 21.0 36.0 234 15.2 39.6 14.4 183 225 196 1130 197 225 213 1145
230-3-60 48.1 351 27.6 191 27.6 191 4.2 21.0 36.0 234 15.2 39.6 13.0 183 225 197 1130 196 225 212 1143
460-3-60 24.7 197 12.8 100 12.8 100 2.1 10.5 18.0 117 8.2 19.8 6.5 91 110 98 596 98 110 105 602
YV40
(40)
575-3-60 22.4 135 9.6 78 9.6 78 1.6 7.8 14.2 95.94 6.1 15.8 5.2 74 90 79 450 79 100 85 455
208-3-60 67.3 485 39.1 267 39.1 267 7.2 39.6 36.0 234 15.2 39.6 14.4 242 300 259 1491 257 300 276 1505
230-3-60 67.3 485 39.1 267 39.1 267 6.8 39.6 36.0 234 15.2 39.6 13.0 241 300 257 1491 254 300 272 1504
460-3-60 32.7 215 18.6 142 18.6 142 3.4 19.8 18.0 117 8.2 19.8 6.5 118 150 126 735 124 150 134 741
YV50
(50)
575-3-60 26.3 175 15.4 103 15.4 103 2.7 15.8 14.2 95.94 6.1 15.8 5.2 95 110 101 572 100 125 107 577
