Table 46: YV35 to YV40 physical data
Models
Component
YV35 YV40
Nominal tonnage 35 40
Compressors 2 Stage 4 Stage 2 Stage 4 Stage
Type Scroll Scroll Scroll Scroll
Quantity 2 3 2 3
Unit capacity steps (%) 50 / 100 25 / 50/ 75 / 100 50 / 100 25 / 50/ 75 / 100
Condenser coil data
Face area (sq. ft) 61.6 112.4
Type MCHX MCHX
Thickness (mm) 20 20
FPI 23 23
Circuitry type 2-Pass 2-Pass
Evaporator coil data
Face area (sq. ft) 34.4 38.9
Rows 4 4
Fins per inch 15 15
Tube diameter 3/8 3/8
Circuitry type Intertwined Intertwined
Refrigerant control TXV TXV
Condenser fan data
Quantity 4 4
Fan diameter (in.) 30 30
Type Prop Prop
Drive type Direct Direct
Number of motors 4 4
Motor HP each 1 1
RPM 1140 1140
Nominal total CFM 29800 34109
Belt drive evap fan data
Quantity 2 2
Fan size (in.) 18x18 20x18
Type Centrifugal Centrifugal
Static range Std Med High Std Med High
Motor sheave 1VP65 2VP60 2VP60 1VP60 1VP75 2VP60
Blower sheave 1B5V124 2B5V94 2B5V86 1B5V124 1B5V136 2B5V94
Belt BX82 BX75 5VX780 5VX830 5VX880 5VX780
Motor HP each 7.5 10.0 15.0 10.0 15.0 20.0
Motor RPM 1800 1800 1800 1800 1800 1800
Frame size 213T 215T 254T 215T 254T 256T
Filters
9 - (20 x 20 x 2)
3
,
4
4 - (20 x 20 x 2)
3
,
4
9 - (20 x 20 x 4)
5
4 - (20 x 20 x 4)
5
3 - (20 x 25 x 2)
3
,
4
8 - (20 x 25 x 2)
3
,
4
Quantity - size
3 - (20 x 25 x 4)
5
8 - (20 x 25 x 4)
5
ID Blower power (kW)
3089
1
/ 3603
2
3046
1
/ 3690
2
5778
1
/ 6566
2
5470
1
/ 6217
2
