Application Data (Cont'd)
TABLE 7 - HYBRID FALLING FILM EVAPORATOR WATER FLOW RATE LIMITS GPM (L/S) – BASED UPON
STANDARD TUBES @ DESIGN FULL LOAD CONDITIONS
HYBRID FALLING FILM EVAPORATORS
MODEL
1 PASS 2 PASS 3 PASS
MIN MAX MIN MAX MIN MAX
AC
705
(44)
2819
(178)
352
(22)
1194
(75)
235
(15)
825
(52)
AD
882
(56)
3527
(223)
441
(28)
1436
(91)
294
(19)
1018
(64)
A3
674
(43)
2695
(170)
337
(21)
1347
(85)
225
(14)
898
(57)
A4
812
(51)
3248
(205)
406
(26)
1624
(102)
271
(17)
1083
(68)
CC
796
(50)
3186
(201)
398
(25)
1410
(89)
265
(17)
945
(60)
CD
999
(63)
3995
(252)
499
(32)
1734
(109)
333
(21)
1178
(74)
CE
1270
(80)
5082
(321)
635
(40)
2140
(135)
423
(27)
1484
(94)
C3
746
(47)
2983
(188)
373
(24)
1492
(94)
249
(16)
994
(63)
C4
938
(59)
3753
(237)
469
(30)
1877
(118)
313
(20)
1251
(79)
C5
1221
(77)
4884
(308)
611
(39)
2442
(154)
407
(26)
1628
(103)
DC
796
(50)
3186
(201)
398
(25)
1214
(77)
265
(17)
809
(51)
DD
999
(63)
3995
(252)
499
(32)
1501
(95)
333
(21)
1010
(64)
DE
1270
(80)
5082
(321)
635
(40)
1865
(118)
423
(27)
1275
(80)
D3
746
(47)
2983
(188)
373
(24)
1463
(92)
249
(16)
982
(62)
D4
938
(59)
3753
(237)
469
(30)
1803
(114)
313
(20)
1228
(77)
D5
1221
(77)
4884
(308)
611
(39)
2261
(143)
407
(26)
1578
(100)
EC
980
(62)
3919
(247)
490
(31)
1758
(111)
327
(21)
1168
(74)
ED
1296
(82)
5183
(327)
648
(41)
2289
(144)
432
(27)
1537
(97)
EE
1637
(103)
6548
(413)
819
(52)
2831
(179)
546
(34)
1929
(122)
E3
986
(62)
3946
(249)
493
(31)
1973
(124)
329
(21)
1315
(83)
E4
1233
(78)
4932
(311)
617
(39)
2466
(156)
411
(26)
1644
(104)
E5
1522
(96)
6087
(384)
761
(48)
3044
(192)
507
(32)
2029
(128)
FC
980
(62)
3919
(247)
490
(31)
1508
(95)
327
(21)
998
(63)
FD
1296
(82)
5183
(327)
648
(41)
1972
(124)
432
(27)
1316
(83)
FE
1637
(103)
6548
(413)
819
(52)
2452
(155)
546
(34)
1654
(104)

York YK Specifications

General

Model	YK
Type	Centrifugal Chiller
Refrigerant	R-134a
Frequency	50/60 Hz
Compressor Type	Centrifugal
Application	Commercial and Industrial
Cooling Capacity Range	400 to 2, 500 tons
Full Load Efficiency	0.50 to 0.60 kW/ton
Efficiency	Varies by model (See specific model data)
Operating Temperature Range	Varies by model (See specific model data)
