York YMC2 - FIGURE 37 - Left Side of 1278 A AMP Drive Cabinet

JOHNSON CONTROLS
115
SECTION 4 - VSD OPERATION
FORM 160.84-OM1
ISSUE DATE: 9/21/2017
4
FIGURE 37 - LEFT SIDE OF 1278A AMP DRIVE CABINET
Cooling
Fans
Voltage
Transient
Board
Line Voltage
Isolation
Board
Drive Logic
Board
Cooling
Coil
Circuit
Breaker
Input Power
Fuses
LD21206
