Zanussi ZDLN2621 - Product Description; Control Panel Overview

PRODUCT DESCRIPTION
5
4
89
10
67
11
12
2
3
1
1
Ceiling spray arm
2
Upper spray arm
3
Lower spray arm
4
Filters
5
Rating plate
6
Salt container
7
Air vent
8
Rinse aid dispenser
9
Detergent dispenser
10
Lower basket
11
Upper basket
12
Cutlery drawer
The graphic is a general overview. For
more details, refer to other chapters or
documents provided with the
appliance.
CONTROL PANEL
1 2 3 4 5 6
1
On/Off button/Reset button
2
Delay start button
3
Indicators
4
Programme buttons
5
