Page - 52/100 AE0ZP0EC - AC-0 SSL SENSORED - User Manual
Flow chart showing how to make changes to OPTIONS Menu.
Opening Zapi Display
AC0 ZP 1.00
24V 250A 00000
Push ROLL UP + SET UP simultaneously to enter
CONFIG MENU
% ' %
' ' '
The Display will show: SET MODEL
CONFIG MENU
SET MODEL
Press ROLL UP or ROLL DOWN button until SET
OPTIONS menu appear.
% ' '
' ' '
The Display will show: SET OPTIONS
CONFIG MENU
SET OPTIONS
Press ENTER to go in the SET OPTIONS MENU
' % '
' ' '
The Display will show the first OPTION
HOURCOUNTER
RUNNING
Press SET UP or SET DOWN button in order to
modify the OPTION
' ' %
' ' %
The Display will show the new option
HOURCOUNTER
KEYON
Press OUT to exit the menu
' ' '
' % '
The Display will ask “ARE YOU SURE?”
ARE YOU SURE?
YES=ENTER NO=OUT
Press ENTER for YES, or OUT for No
' % '
' ' '
' ' '
' % '
The Display will show: SET OPTIONS
CONFIG MENU
SET OPTIONS
Press OUT again. Display now will show the
opening Zapi menu.
' ' '
' % '
Figure 9–5
