Zapi AC-0 SSL User Manual

AE0ZP0EC - AC-0 SSL SENSORED - User Manual Page - 53/100
Flow chart showing how to make changes to ADJUSTMENTS Menu.
Opening Zapi Menu
AC0 ZAPI V0.0
24V 150A 00000
Press Top Left & Right Buttons to enter CONFIG
MENU
% ' %
' ' '
The Display will show: SET MODEL
CONFIG MENU
SET MODEL
Press ROLL UP button until ADJUSTMENTS
MENU appears
% ' '
' ' '
ADJUSTMENTS appears on the display
CONFIG MENU
ADJUSTMENTS
Press ENTER to go into the ADJUSTMENTS
MENU
' % '
' ' '
The display will show: SET BATTERY TYPE
BATTERY TYPE
24V
Press ROLL UP or ROLL DOWN button until the
desired parameter is reached
% ' '
% ' '
The desired parameter is appears
THROTTLE 0 ZONE
3%
Press SET UP or SET DOWN button to modify the
adjustment
' ' %
' ' %
THROTTLE 0 ZONE
7%
Press OUT
' ' '
' % '
Press ENTER to confirm
' % '
' ' '
Repeat the same from 5 to 12 points for the other
adjustment
Figure 9–6

Zapi AC-0 SSL Specifications

General

Brand	Zapi
Model	AC-0 SSL
Category	Inverter
Language	English
