26) V2 OPENING RAMP
(MDI-PRC version only). A time units value (from 0.0 to 2.0 seconds). This
parameter determines the ramp of voltage applied on the EVP2 (pin #9 MDI-
PRC) in the opening transition (if proportional); this is the time necessary to
go from the minimum to the maximum voltage. If the electrovalve is
programmed like an On/Off valve this parameter is not effective.
27) V1 CLOSING RAMP
(MDI-PRC version only). A time units value (from 0.0 to 2.0 seconds). This
parameter determines the ramp of voltage applied on the EVP1 (pin #8 MDI-
PRC) in the closing transition (if proportional); this is the time necessary to go
from the maximum to the minimum voltage. If the electrovalve is programmed
like an On/Off valve this parameter is not effective.
28) V2 CLOSING RAMP
(MDI-PRC version only). A time units value (from 0.0 to 2.0 seconds). This
parameter determines the ramp of voltage applied on the EVP2 (pin #9 MDI-
PRC) in the closing transition (if proportional); this is the time necessary to go
from the maximum to the minimum voltage. If the electrovalve is programmed
like an On/Off valve this parameter is not effective.
The following table shows the different values at which the parameters can be
set.
PROGRAMMED LEVEL
PARAMETER UNIT
0 1 2 3 4 5 6 7 8 9
ACCELER. DELAY (*) Sec. 2.05 3.00 3.05 4.00 4.05 5.00 5.05 6.00 6.05 7.00
RELEASE BRAKING (**) Sec. 5.05 5.00 4.05 4.00 3.05 3.00 2.05 2.00 1.05 1.00
INVERS. BRAKING (**) Sec. 5.05 5.00 4.05 4.00 3.05 3.00 2.05 2.00 1.05 1.00
PEDAL BRAKING (**) Sec. 5.05 5.00 4.05 4.00 3.05 3.00 2.05 2.00 1.05 1.00
SPEED LIMIT BRK. (**) Sec. 8.09 8.03 7.07 7.01 6.06 6.00 5.05 4.09 4.04 3.08
BRAKE CUTBACK (**) Sec. 5.05 5.00 4.05 4.00 3.05 3.00 2.05 2.00 1.05 1.00
MAX SPEED FORW Hz 65 80 95 110 125 140 155 170 185 200
MAX SPEED BACK Hz 65 80 95 110 125 140 155 170 185 200
CUTBACK SPEED %Max Sp 10 15 20 25 37 50 62 75 87 100
CUTBACK SPEED 2 %Max Sp 10 15 20 25 37 50 62 75 87 100
CUTBACK SPEED 3 %Max Sp 10 15 20 25 37 50 62 75 87 100
H&S CUTBACK %Max Sp 10 15 20 25 37 50 62 75 87 100
FREQUENCY CREEP Hz 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0
MAXIMUM CURRENT %IMAX 47 53 58 64 70 76 82 88 94 100
INCHING SPEED Hz 0 2 4 6 8 10 12 14 16 18
INCHING TIME Sec. 0.02 0.05 1.00 1.04 1.08 2.03 2.07 3.01 3.06 4.00
AUXILIARY TIME Sec. 0.0 0.2 0.4 0.8 1.0 1.5 2.0 3.0 4.0 5.0
MIN VALVE 1 This parameter can be adjusted from 1 to 255 with regulation of 1digit
MIN VALVE 2 This parameter can be adjusted from 1 to 255 with regulation of 1digit
MAX VALVE 1 This parameter can be adjusted from 1 to 255 with regulation of 1digit
MAX VALVE 2 This parameter can be adjusted from 1 to 255 with regulation of 1digit
