zarges PaxTower S-PLUS 1T User Manual

45
5. Attach the horizontal
brace to lowermost
rung.
6. Attach the diagonal
brace to the lowermost
rung.
1.
2.
7. Connect the one-metre
push-on end frames to-
gether until the spring
clips snap into place.
8. Insert the one-metre
push-on end frames
(which are now con-
nected) and push them
in until the spring clips
snap into the base unit.
9. Insert the two-metre
push-on end frame
and push it in until the
spring clips snap into
the base unit.
10. Install the two advanced
guardrails (see “Assem-
bling scaffold towers of
size 2” on page41,
Steps 7 and 8).
1.
2.
