Chapter 4 Guide of quick operation
4.1 Rebar test
4.1.1 On-site preparation
Before the start of test, grind or polish the tested object first. Uneven
surface of objects will affect test results. Try best to keep the surface
of objects even, it is conducive to sensor sliding on component
surface.
4.1.2 To connect sensor to host
To insert one end plug (in black) of signal wire to the left side
corresponding socket of host, rotating clockwise and locking. Then
insert the other end plug into sensor socket and lock in the same
manner (see figure 4-1 for connection diagram)
Figure 4-1 Connect rebar sensor with host
