67
Figure 4-6 Single electrode connection
Figure 4-7 Double electrode connection
If testing with double-electrode method, it is necessary to install
the two copper sulfate electrode on the double-electrode support
and connect the two electrodes to corrosion sensor port of
instrument with double-electrode signal wire, see fig.4-7.
4.2.2 Starting rust test
1. To start up the instrument and enter into “Method”, “Icon”
“Scan Area” under “Rust Test” respectively. Select test
method and icon, set number, dot pitch and number of
measuring points etc and then select “Start Scan” to test
interface.
