Zebra 110Xi4 User Manual

Specifications
Media Specifications
164
P1009874-001 Xi4 User Guide 3/12/09
140Xi4, 170Xi4, and 220Xi4 Black Mark Sensing Only
Media Specifications 140Xi4 170Xi4 220Xi4
Mark length
(measuring parallel to label or tag
edge)
Minimum 0.12 in. (3 mm) 0.12 in. (3 mm) 0.12 in. (3 mm)
Maximum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Mark width (measuring to
perpendicular label or tag edge)
Minimum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Maximum Full media width Full media width Full media width
Mark location within 0.040 in. (1 mm) of
the inside media edge
within 0.040 in. (1 mm) of
the inside media edge
within 0.040 in. (1 mm) of
the inside media edge
Mark density in Optical Density Unit (ODU) >1.0 >1.0 >1.0

Zebra 110Xi4 Specifications

General

Maximum resolution	203 x 203 DPI
Core diameter	76 mm
Ribbon length	300 m
Media thickness	0.076 - 0.305 mm
Maximum media length	3810 mm
Maximum roll diameter	203 mm
Supported paper width	102 mm
Media thickness (imperial)	0.003 - 0.012 \
Maximum media length (imperial)	150 \
Supported paper width (imperial)	4 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	50 lbs
Dimensions (WxDxH)	261.9 x 517.5 x 393.7 mm
Flash memory	8 MB
Certification	-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory	16 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	XML, ZPL, ZPL II
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Power requirements	90 - 264 VAC, 48 - 62 Hz

Weight and Dimensions

Weight	22700 g
