Operations
Load Media in Rewind Mode
66
P1009874-001 Xi4 User Guide 3/12/09
Remove Media Liner from the Rewind Spindle
Rewind mode uses the rewind spindle to wind media, while Peel-Off mode uses the rewind
spindle to wind used liner. Remove the media or the liner from the rewind spindle each time
that you change media.
To remove media or liner from the rewind spindle, complete these steps:
1. Has the media run out?
Important • It is not necessary to turn off the power to remove media or liner from the
rewind spindle. If power is turned off, all label formats and images, as well as any
temporarily saved parameter settings stored in the printer’s internal memory, are lost. When
power is turned back on, these items must be reloaded.
If... Then...
No a. Create slack in the media or liner by rotating the rewind spindle
slightly clockwise.
b. Cut or tear the media or liner at the rewind spindle.
Ye s Continue with the next step.
To Next Page
