65
Operations
Load Media in Rewind Mode
3/12/09 Xi4 User Guide P1009874-001
20. Tighten the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
21. Push down the printhead assembly (1), and then rotate the printhead-open lever (2)
clockwise until it locks into place.
The labels wind on the rewind spindle or core.
