Zebra 110Xi4 - Page 64

Operations
Load Media in Rewind Mode
64
P1009874-001 Xi4 User Guide 3/12/09
18. Rotate the spindle counterclockwise several turns to wind the media liner over the hook
and remove any slack.
19. Align the media with the inner media guide (1). Slide in the outer media guide (2) until it
just touches the edge of the media.
2
1
1
2
