Printer Setup
Select a Data Communication Interface
26
P1009874-001 Xi4 User Guide 3/12/09
USB No additional configuration is necessary.
Caution • Be careful not to plug the USB cable into the wired Ethernet
print server connector on the printer because doing so will damage the
connector.
Twinax/Coax No additional configuration is necessary. To purchase this option, contact
your authorized Zebra reseller.
Table 4 • Connecting the Printer to a Computer or Network (Continued)
Interface Connection and Configuration

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra 110Xi4 and is the answer not in the manual?

Zebra 110Xi4 Specifications

General IconGeneral
Maximum resolution203 x 203 DPI
Core diameter76 mm
Ribbon length300 m
Media thickness0.076 - 0.305 mm
Maximum media length3810 mm
Maximum roll diameter203 mm
Supported paper width102 mm
Media thickness (imperial)0.003 - 0.012 \
Maximum media length (imperial)150 \
Supported paper width (imperial)4 \
RS-232 ports1
Standard interfacesUSB 2.0
Connectivity technologyWired
Weight (imperial)50 lbs
Dimensions (WxDxH)261.9 x 517.5 x 393.7 mm
Flash memory8 MB
Certification-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory16 MB
Built-in barcodesCode 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languagesXML, ZPL, ZPL II
Storage temperature (T-T)-40 - 140 °F
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)5 - 85 %
Operating relative humidity (H-H)20 - 85 %
Power requirements90 - 264 VAC, 48 - 62 Hz
Weight and Dimensions IconWeight and Dimensions
Weight22700 g
