57
Operations
Load Media in Cutter Mode
3/12/09 Xi4 User Guide P1009874-001
8. Align the media with the inner media guide (1). Slide in the outer media guide (2) until it
just touches the edge of the media.
9. Tighten the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
1
2
1
