Zebra 110Xi4 - Page 78

Operations
Adjust Transmissive Media Sensors
78
P1009874-001 Xi4 User Guide 3/12/09
3. Using a thin, flat-blade screwdriver, loosen the upper media sensor adjustment screw.
4. Slide the upper media sensor along the slot to the desired position.
XX
YY
ZZ
XX
YY
ZZ
