Zebra CS6080 Series User Manual

Quick Start Guide 19
Button Actions
To actuate the buttons, apply a finite force to
the button recess.
For subsequent button actuations, remove
force, and then re-apply force.
Action Description
Scan Button (...)
Single press Trigger
Double press Issue connection to
last known address if
disconnected/if
connected in HID
mode to an Apple
device, will send
show/hide keypad
Hold for 3 seconds Battery status
Hold until beam goes
off plus 5 seconds
longer
Night mode
Programmable Button (-)
Single press (not in
cradle) default*
Show/hide keypad
Single press option 2 Programmable trigger
Single press option 3 Toggle lamp mode
(cordless only)
Single press in cradle Toggle lamp mode
(cordless only)

Zebra CS6080 Series Specifications

General

Brand	Zebra
Model	CS6080 Series
Category	Barcode Reader
Language	English
