Getting Started 1 - 5
Charging
The headset batteries are charged in a toaster which uses either a one slot cradle or a five slot cradle.
Charging Configurations
Connect the Charger
The 8-Slot Battery Charger charges up to eight spare batteries.
To connect the charger:
Connect one end of the power supply to the charging base and the other end into the outlet.
Figure 1-3
Battery Toaster 1 Slot - SE Cradle and Battery Toaster 5 Slot - SE Cradle
Table 1-2 Charging Configurations
Model Includes
Battery Toaster 1 Slot-SE Cradle 1-Slot Base Cradle
Toaster Cup
PS000084A01 adapter plus CBL-DC-388A1-01 DC
cable
Battery Toaster 5 Slot-SE Cradle 5-Slot Base Cradle
Toaster Cup
4 WT/WT Charging Cups
PS000086A01 adapter plus CBL-DC-381A1-01 DC
cable
NOTE Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
7-1.
