B - 2 HS3100 Rugged Bluetooth Headset User Guide
The HS3100 is optimized for real-time two-way speech applications and uses the BT Hands Free Profile. A host
connected to HS3100 can remotely control audio volume and microphone gain of the headset.
The HS3100 sends the host its battery information (Serial Number, State of Charge and State of Health), the power
state (main or backup battery) and headset information (Serial Number, HW and FW version, and its capabilities).
Receive
Frequency
Response
300 Hz to 6 kHz
Speaker
Sensitivity
89 dB SPL with 1.0 Vrms @ 1 kHz
Bluetooth Bluetooth Class II, v 3.0; Bluetooth Hands-free Profile (HFP 1.6)
NFC NFC tag used for Tap-to-Pair
User Environment
Zebra Mobile
Computers
Compatibility
Visit www.zebra.com/hsheadsets for the most current list of compatible mobile computers.
User Interfaces LED: Bi-color LED for headset status
Buttons: Three functional buttons
Operating
Temperature
-30°C (-22°F) to +50°C (+122°F)
Storage
Temperature
-40°C (-40°F) to +60°C (+140°F) incl. battery
-40°C (-40°F) to +70°C (+158°F) excl. battery
Sealing Rating IEC 60529: IP67
Humidity 5% to 95% non-condensing
Drop Rating 6 ft./1.8 m drop to concrete (36 drops, over operating temperature range)
Tumble Rating 1,000 tumbles @ 0.5 m (room temperature)
Vibration Since 5-2000Hz, 4g peak, 1 hour per axis; Random 20-2000Hz, 6g RMS or 0.04g2/Hz, 1 hour
per axis
Electrostatic
Discharge (ESD)
+/-20kV air discharge, +/-10kV contact discharge, +/-10kVdc indirect discharge
Software Compatibility
Software TekSpeech Pro 4, Android EMDK
Table B-1 HS3100 Bluetooth Headset Technical Specifications (Continued)
Item Description
