Peel/Rewind Upgrade

Install the Rewind Pan

79835L-001 B ZM400/ZM600 Installation Instruction 7/30/07

2. Install, but do not tighten, the main frame mounting screws provided in the kit.

3. Recheck the alignment from step 1 and then tighten the two screws on the rear of the main

frame.

4. Tighten the rest of the main frame mounting screws.

5. Reinstall the rear cover by sliding it under the screw loosened previously on the main

frame. Leave the screw loose.

6. Using the two screws supplied in the kit, attach the rear cover to the rewind pan.

7. Tighten the two screws and the one screw on the main frame.

Note • The oversize mounting hole in the pan allows for adjustment of the front of the pan

to align with the door.

Other manuals for Zebra ZM400

Questions and Answers:

Need help?

Do you have a question about the Zebra ZM400 and is the answer not in the manual?

Printer Specifications

resolution	203 dpi/8 dots per mm, 300 dpi/12 dots per mm, 600 dpi/24 dots per mm
print width	4.09”/104 mm
print length	157”/3, 988 mm with 203 dpi, 73”/1, 854 mm with 300 dpi, 39”/991 mm with 600 dpi
maximum label and liner width	4.5”/114 mm
ribbon width	2.00”/51 mm to 4.33”/110 mm

Environmental

operating temperature	32º F/0º C to 104º F/40º C (Direct Thermal), 40º F/5º C to 104º F/40º C (Thermal Transfer)
storage temperature	-40º F/-40º C to 140º F/60º C
operating humidity	20-85% non-condensing
storage humidity	5-85% non-condensing

Weight and Dimensions

Printer Specifications

resolution	203 dpi/8 dots per mm, 300 dpi/12 dots per mm
print width	6.6”/168 mm
print length	102”/2, 590 mm with 203 dpi, 45”/1, 143 mm with 300 dpi
maximum label and liner width	7.0”/178 mm
ribbon width	2.00”/51 mm to 6.85”/174 mm

Environmental

operating temperature	32º F/0º C to 104º F/40º C (Direct Thermal), 40º F/5º C to 104º F/40º C (Thermal Transfer)
storage temperature	-40º F/-40º C to 140º F/60º C
operating humidity	20-85% non-condensing
storage humidity	5-85% non-condensing

Weight and Dimensions
