Zebra ZM400 User Manual

57
Configuration
Control Panel Parameters
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Set Maximum Label Length
This parameter is used during the media portion of the calibration process.
Always set maximum label length to a value that is at least 1.0 in.
(25.4 mm) greater than the actual label length (Figure 12). If the value is set
to a smaller value than the label length, the printer assumes that continuous
media is loaded, and the printer cannot calibrate.
For example, if the label length is 5.0 inches (126 mm), set the parameter
for 6.0 inches (152 mm). If the label length is 7.5 inches (190 mm), set the
parameter for 9.0 inches (229 mm).
Figure 12 • Label Length
Default Value: 12.0 inches (305 mm).
Selections: Values are adjustable in one-inch (25.4 mm) increments.
To change the value shown:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) or MINUS (-) to change the value shown.
3. Press
SELECT to accept any changes and deselect the parameter.
Table 11 • Printer Parameters (Page 4 of 20)
Parameter
Action/Explanation
}
2
1
Label length (including interlabel gap)
2
Interlabel gap
3
Set maximum label length to approximately
this value
1
3
