FDM Technical Data and Operating Instructions
Power Supply Mascot/2020 REF-No. 01811513
For the following platforms: FDM-1.5, FDM-2, FDM-3
FDM-1.7, FDM2.4
FDM-J1, FDM-J1.8SQ
Technical Data
Pin arrangement / polarity
Before connecting the measuring system to the mains, compare the
nameplate indications of the power supply and the treadmill in terms
of mains voltage and mains frequency with the local characteristics.
Only connect when they are in accordance.
Carry out a visual examination of power supply, mains connection
voltage and socket as well as earthing contacts before connecting
resp. commissioning the measuring system. Damaged power sup-
plies, cables or connection sockets immediately must be replaced by
a person authorised to do so.
„-“Contakt: Outer contact oft
he hollow plug
„+“Contact: Inner contact of
the hollow plug
