zebris FDM-SX - FDM Platforms for Gait Training and Rehabilitation Applications

zebris Medical GmbH
FDM Technical Data and Operating Instructions
Page 16/54
3.2.5 FDM platforms for gait training and rehabilitation applications
Type
FDM-1.7
REF.-No.
01243034
Outer dimensions
1820 x 600 x 21 mm (L x W x H)
Weight
approx. 22 kg
Measuring frequency
100 Hz
Number of sensors
44 x 136 / 5984
Sensor surface
1730 x 560 mm (L x W)
Resolution
1/2 “ resp. 0.6 sensors / cm²
Infrared interface
optional
Type
FDM-2.4
REF.-No.
01243035
Outer dimensions
2510 x 600 x 21 mm (L x W x H)
Weight
approx. 31 kg
Measuring frequency
100 Hz
Number of sensors
44 x 190 / 8360
Sensor surface
2410 x 560 mm (L x W)
Resolution
1/2 “ resp. 0.6 sensors / cm²
Infrared interface
optional
Connector box
at bottom side
)
Connector box
at bottom side
)
Ready for installation
in h/p/cosmos parawalk
