ZEISS ESSENTIAL OPERATION CONTROLS ON AXIO OBSERVER MATERIALS Axio Observer
14 431004-6044-008 09/2017
Axio Observer 3 Axio Observer 5 Axio Observer 7
40 Binocular section of tube Binocular section of tube Binocular section of tube
41 Eyepiece Eyepiece Eyepiece
42
Eyepiece focusing ring Eyepiece focusing ring Eyepiece focusing ring
10 ESSENTIAL OPERATION CONTROLS ON AXIO OBSERVER MATERIALS
Fig. 2 Essential operation controls on Axio Observer materials
