33
MCS 600 | User Manual
MCS 600
3.8 BLX 600/SMA lamp cassette
3.8.1 Overview
Fastening screws
SMA connector
Handle rail
Interface for MCS 600 housing
1
2
3
4
Fig. 15 BLX 600/SMA lamp cassette
1
2
3
Fig. 16 BLX 600/SMA lamp cassette, rear view
4
